794954-4

Business

Product Category	Pin & Socket Connectors	Standard Package	Bulk
Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	Approval Agency	:CSA, UL
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-2

Voltage Rating	600 V	Current Rating (Max)	9 A
Connector - Voltage Input	w/o terminals

Color	Natural	Depth	20mm
Pitch	4.2 mm	Length	10mm
Weight	0.002	Material	Nylon
Packaging	Bulk	Row Spacing	0.165" (4.20mm)
Contact Type	Female Socket	Pitch - Post	4.2mm
Mounting Type	Straight	Connector Type	Receptacle
Fastening Type	Latch Lock	Mounting Style	Free Hanging
Number of Rows	2	Material Finish	:-
Housing Material	Nylon	Package Quantity	1
Connector - Cable	plug	Termination Style	Crimp
1st Contact Gender	Socket (Female)	Number of Contacts	4
Contact Termination	Crimp	Number of Positions	4
1st Connector Mounting Feature	2x2

Spg	1	Note	Contacts Not Provided
Type	Housing	Gender	RCP
Series	PE	CAD Drawing	3D CAD Model
Product Type	Housing	Adapter Series	VAL-U-LOK
Number of Units	1	Number of Circuits	4
For Use With/Related Products	Wire-to-Board Connector, Wire-to-Panel Connector, Wire-to-Wire Connector
