6643232-1
| Manufacturer | |
| Description | Conn Power SKT 1 POS Solder RA Thru-Hole 1 Terminal 1 Port ICCON Single-Pole Power Connectors CONN SOCKET ICCON R/A PCB Power to the Board SNGL POLE PWR CONN RA THRU HOLE Conn Power SKT 1 POS Solder RA Thru-Hole 1 Terminal 1 Port Product Highlights:ConnectorSocketFootprint = 7.62 x 2.54 mmRight Angle Mount AngleMount Style = Through-Hole CONNECTOR, POWER, SOCKET, R/A, 1WAY |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | A36258 | Product Category | Power to the Board |
| Standard Package | Rail / Tube | Factory Pack Quantity | 112 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85366990 |
| Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250V | Current Rating (Max) | 35A |
Mechanical
| Color | Black | Weight | 0.005 |
| Packaging | Tube | Termination | Solder |
| Housing Color | No | Mounting Type | Through Hole |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Silver |
| Mounting Style | Through-Hole | Plating - Body | Gold over Nickel |
| Connector Style | Power | Material - Core | Beryllium Copper |
| Contact Material | Brass | Housing Material | Polyester GF 30% |
| Outline L x W x H | 7.62 x 2.54 [.300 x .100] | Contact Termination | :Through Hole Right Angle |
| Number of Positions | 1 | Contact Layout, Typical | 1 Power |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | Power | Gender | SKT |
| Series | :ICCON | Product Type | Connector |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -40°C ~ 105°C | ||
Documents & Media
Online Document
