647893-8
| Manufacturer | |
| Description | Connector Accessories Kit And Spring Subassembly Heavy Duty Power Connectors SERIES 50 CONN 10-12 AWG YELLOW Power Connectors CONN PLUG 2POS 10-12 AWG SILVER Power Connectors Product Highlights:Connector Kit50 AMP SeriesConnector Type = 2-Pole Battery ConnectorWire Size (AWG/CM) = 10-12 AWGCurrent = 50 Amps.Search Keywords:Power Wiring Devices, Battery Connectors & Battery Assemblies, Anderson plug, Anderson connectors, Anderson power, Anderson APP, Anderson powerpole, Power Series, FPR, Finger Probe Resistant SRS 50 CONN KIT,YELOW,10-12AWG |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Pack | 1 | Product Category | Heavy Duty Power Connectors |
| Standard Package | Bulk | Factory Pack Quantity | 1 |
Compliance
| RoHS | RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | Standard Number | UL |
| UL Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 12 V | Voltage - Supply | 600 |
| Connector Impedance | 压接 | Current Rating (Max) | 50 A |
Mechanical
| Color | Yellow | Width | 35.05 mm [ 1.38 in ] |
| Height | 15.88 mm [ .625 in ] | Length | 48.23 mm [ 1.9 in ] |
| Sealed | 不密封 | Packaging | Bulk |
| Body Color | 黄色 | Cable Type | 绞线 |
| Wire Gauge | 10-12 AWG | Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) | Cable Diameter | 6088 – 12066 |
| Connector Type | Assembly (Kit), Non Gendered | Contact Finish | Silver |
| Fastening Type | Spring Retention | Number of Rows | 1 |
| Connector Style | 2 Poles | Contact Material | Copper |
| Housing Material | Polycarbonate (PC) | Package Quantity | 1 |
| Panel Mount Type | 不带 | Termination Style | 插针/插座 |
| Number of Positions | 2 | Shell Size - Insert | 母端, 母端 |
| Material - Insulation | Polycarbonate (PC) | Mounting Hole Diameter | 带有 |
| Wire Gauge or Range - AWG | 12 | ||
Product Info
| Type | Kit | Product Type | 连接器组件 |
| RF Family/Standard | 647893 | Application Specifics | Power |
| Assembly Configuration | Kit | ||
