5747150-8
| Manufacturer | |
| Description | Conn D-Subminiature SKT 9 POS 2.74mm Solder ST Thru-Hole 9 Terminal 1 Port D-Sub Standard Connectors RECP FRNT MTL SHL 9P threaded inserts Standard Board Mount Connectors CONN D-SUB RECPT STR 9POS PCB AU AMPLIMITE HD-20 d-sub PCB socket, 9 way Conn D-Subminiature SKT 9 POS 2.74mm Solder ST Thru-Hole 9 Terminal 1 Port Product Highlights:Number of Positions = 9ReceptaclePCB Mount Angle = VerticalProduct Series = HD 20With Mating Connector LockSearch Keywords:Subminiature D, AMPLIMITE, MIL-C-24308, DIN 41652, Mark II, Mark III, DIN 41494, box to box, military/aerospace, 13C3, 3C3, HD-22,
ACTION PIN, d-sub, d sub, dsub CONNECTOR, D SUB, RECEPTACLE, 9WAY Conn;D-Sub;PCBSocket;9Pos;STR;HD-20Series;20AWG;FrontMetalShell TE Connectivity Amplimite HD-20 系列 2.74mm 节距 9 路 直向 通孔安装 PCB D-sub 连接器 插座 09 RCPT SP/FMS INSRT |
| Category |
Business
| Product Category | D-Sub Standard Connectors | Standard Package | Rail / Tube |
| Factory Pack Quantity | 17 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | Tariff No | 85366910 |
| Rad Hardened | No | Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Grounding | Without | Range deg/s | :TE CONNECTIVITY - Amplimite HD-20 Series |
| Voltage Rating | 125V | Current Rating (Max) | 6A |
| Voltage - Supply (Min) | 250VAC | ||
Mechanical
| Color | Black | Depth | 12.55mm |
| Pitch | 2.74 mm | Width | 12.16mm |
| Height | 12.16 mm | Length | 30.89mm |
| Sealed | No | Weight | 0.005 |
| Packaging | Tube | Shell Size | 1 |
| Termination | Solder | Contact Type | Signal |
| 2nd Connector | With | Contact Shape | Round |
| Mounting Type | Through Hole | Shell Plating | Tin |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) | Grounding Type | Without |
| Mounting Style | Through Hole | Number of Rows | 2 |
| Shell Material | Steel | Board Thickness | 0.062 â 0.093 [1.57 â 2.36] |
| Connector Style | D-Sub | Insert Material | Brass |
| Locking Feature | Threaded Insert, 4-40 UNC | Material - Body | :Steel |
| Profile (W x H) | Standard | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 30.89 mm |
| Panel Mount Type | Without | Size / Dimension | 0.66 [.026] |
| Grounding Indents | Without | Termination Style | Solder |
| Color - Connectors | None | Number of Contacts | 9 |
| Contact Termination | :Solder | Number of Positions | 9 |
| Shell Size - Insert | Front Metal Shell | Mounting Hole Diameter | 3.05 [.120] |
| Shell Material, Finish | Steel, Tin Plated | Termination Post Length | 3.18 [0.125] |
| Contact Finish Thickness | 30µin (0.76µm) | Shell Size, Connector Layout | 1 (DE, E) |
Product Info
| Note | All receptacles are preloaded with size 20 DF posted socket contacts | Type | D-Subminiature |
| Gender | SKT | Series | HD-20 |
| Manufacturer | AMP | Number of Ports | 1 Port |
Environmental
| Operating Temperature | -55°C ~ 105°C | ||
