Other Names	5650912-5-ND	Standard Pack	30
Product Category	DIN 41612 Connectors	Standard Package	Bulk

RoHS	Lead free / RoHS Compliant	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Interface	Eurocard/DIN 41612	Voltage - Supply	250
Current Rating (Max)	1.5

Color	Gray	Pitch	2.54 mm
Height	11.4 mm [ .45 in ]	Coating	Without
Packaging	Bulk	Thickness	2.36 [0.093]
Termination	Press Fit	Contact Type	Compliant Post
Mounting Type	Through Hole	Connector Type	Plug, Male Pins
Contact Finish	Gold Over Nickel	Mounting Style	带有
Number of Rows	3	Terminal Style	.64 x .64 mm [ .025 x .025 in ]
Insert Material	铜合金	Contact Material	Copper Alloy
Housing Material	Polymer	Mounting Feature	作用/符合标准的尾
Panel Mount Type	通孔 - 焊接	Make Before Break	No
Termination Style	插针	Mating Orientation	Without
Number of Contacts	64	Number of Positions	64
Contact Length - Post	6.35 mm [ .25 in ]	Material - Insulation	Polymer Thermoplastic, Glass Filled
Mounting Hole Diameter	不带	Contact Finish - Mating	锡
Termination Post Length	6.35 [0.250]	Contact Finish Thickness	2.54 – 5.08 µm [ 100 – 200 µin ]

Level, Class	2	Operating Temperature	-55°C ~ 125°C
Thermal Resistance of Package	1.57 mm [ .062 in ]

5650912-5
