485893-2
| Manufacturer | |
| Description | Conn Housing RCP 4 POS 2.54mm Crimp ST Flexible Film Connectors 004 HOUSING FFC PIN 100CL SR CONNECTOR,PINHOUSING,FLEXIBLEFILM,4POS FFC & FPC Connectors 004 HOUSING FFC PIN Conn Housing RCP 4 POS 2.54mm Crimp ST Product Highlights:Housing2.54 mm CenterlineConnector Type = StandardNumber of Positions = 4Number of Rows = SingleSearch Keywords:Circuitry-to-Board, cable to board, board to board, FFC, flat flexible cable, flat flex wire, Easy Mating Connector CONNECTOR,PINHOUSING,FLEXIBLEFILM,4POS,2.54MM,SINGLEROW |
| Category |
Business
| Other Names | 4858932 | Product Category | FFC & FPC Connectors |
| Standard Package | Bulk | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | Yes | ||
Electrical
| Voltage Rating | 300V | Voltage - Supply | 300 VAC |
| Resistance - Input | 5000 | Voltage - Clamping | 720 |
| Connector Impedance | 制动器窗口 | Current Rating (Max) | 2A |
| Voltage - Input (Min) | 300VAC | Voltage - Supply (Min) | 300VAC |
Mechanical
| Color | Black | Depth | 23.62 mm |
| Pitch | 2.54 mm | Height | 6.35 mm |
| Lock Type | 带有 | Packaging | Bulk |
| Body Color | 黑色 | Cable Type | FFC |
| Wire Gauge | 22-32 AWG | 2nd Connector | With |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Standard | Mounting Style | Cable |
| Number of Rows | 1 | Connector Usage | Plug |
| Locking Feature | Detent Windows | Housing Material | Thermoplastic |
| Length - Overall | 16.51 mm | Mounting Feature | Without |
| Package Quantity | 1 | Panel Mount Type | Without |
| Primary Material | FFC | Termination Style | 插针 |
| FFC, FCB Thickness | 0.05-0.13mm | Mating Orientation | With |
| Number of Contacts | 4 | Number of Positions | 4 |
| Mounting Hole Diameter | 带有 | Center Contact Material | 2.54 [0.100] |
Product Info
| Note | Use Extraction Tool No. 91092-1 for round wire contacts. | Type | Housing |
| Gender | RCP | Series | AMP/Slimline |
| Features | Detent Lock | Manufacturer | AMP/Slimline |
| Product Type | Housing | Connection Type | FFC Cable |
Environmental
| Operating Temperature | -65°C ~ 105°C | ||
Documents & Media
