86561-9
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | FFC & FPC Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Leadfree Defin | Reflow solder capable to 245°C, Reflow solder capable to 260°C |
| RoHSELV Compliance | Not ELV/RoHS compliant | ||
Electrical
| Contact Resistance | 45mΩ | Connector Impedance | 刺破式压接 (IDC) |
Mechanical
| Pitch | 2.54 mm [ .1 in ] | Packaging | Bulk |
| Cable Type | Round Wire, Discrete | Wire Gauge | 22-26 AWG |
| Termination | Crimp | Contact Type | Pin |
| Pin or Socket | Pin | Cable Diameter | 0.4mm² |
| Connector Type | Connector FFC-FPC | Contact Finish | Tin-Lead Over Nickel |
| Insert Material | 磷青铜 | Contact Material | Phosphor Bronze |
| Length - Overall | 2.54 [0.100] | Package Quantity | Loose Piece |
| Termination Rows | 压接 | Termination Style | 插针 |
| Contact Termination | Crimp | Insulation Diameter | 1.02 â 1.42 [0.040 â 0.056] |
| Contact Finish Thickness | 100µin (2.54µm) | Wire Gauge or Range - AWG | 22AWG |
| Wire Gauge or Range - mm2 | 0.12-0.40² [26-22] | ||
Product Info
| Mfr | 1.27, 2.33 | Note | Use Extraction Tool No. 91092-1 for end locking slot and Extraction Tool No. 91 |
| Gender | PIN | Series | FFC |
| Product Type | Contacts | ||
Environmental
| Operating Temperature | 105°C | Usable Temperature Range | -55to+105°C |
| Operating Temperature - Junction | 105°C | ||
