Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Approval Agency | :CSA, UL, VDE | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | 600 V | Voltage - Working | :600V |
| Contact Resistance | :3.5mohm | Dielectric Strength | :5000V |
| Current Rating (Max) | 19 A | Insulation Resistance | :1000Mohm |
| Voltage - Supply (Min) | 600VAC | Connector - Voltage Input | sealable |
Mechanical
| Color | Natural | Depth | 27.43mm |
| Pitch | 6.35 mm | Width | 14.73mm |
| Height | 14.73 mm | Weight | 0.004 |
| Material | :Nylon | Packaging | Bulk |
| Wire Gauge | 10-30 AWG | Contact Type | Male or Female |
| Pitch - Post | 6.35mm | Housing Color | White |
| Mounting Type | Straight | Connector Type | Plug |
| Fastening Type | Latch Lock | Mounting Style | Free Hanging |
| Number of Rows | 1 | Locking Feature | lock |
| Material Finish | :- | Contact Material | Phosphor Bronze |
| Housing Material | Nylon | Package Quantity | 500 |
| Connector - Cable | plug | Termination Style | Crimp |
| 1st Contact Gender | Pin (Male) | Color - Connectors | :Opaque |
| Number of Contacts | 4 | Contact Termination | Crimp |
| Number of Positions | 4 | 1st Connector Mounting Feature | 1x4 |
Product Info
| Spg | 500 | Note | Contacts Not Provided |
| Type | Housing | Gender | PL |
| Series | MATE-N-LOK | CAD Drawing | 3D CAD Model |
| Product Type | Plug Housings | Adapter Series | Universal MATE-N-LOK |
| Number of Units | 1 | For Use With/Related Products | Wire-to-Board Connector |
Environmental
| Mating Cycles | :50 | Operating Temperature | -55C to 105C |
Documents & Media
Online Document
