3-643813-6

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	500

RoHS	RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-2

Color	Red	Pitch	2.54 mm
Weight	0.004	Material	polyamide
Packaging	Bulk	Shrouding	No
Wire Type	Discrete or Ribbon Cable	Cable Exit	90Â°
Wire Gauge	22	Termination	IDT
Contact Type	Female Socket	Lead Spacing	:2.54mm
Pitch - Post	2.54mm	Polarization	Polarizing Tab
2nd Connector	With	Housing Color	Red
Mounting Type	Free Hanging (In-Line)	Connector Type	Closed End
Contact Finish	Tin Over Nickel	Fastening Type	Locking Ramp
Mounting Style	Wire	Number of Rows	1
Connector Usage	Receptacle	Contact Material	Copper Alloy
Housing Material	Nylon	Mounting Feature	Without
Package Quantity	Loose Piece	Panel Mount Type	Without
Primary Material	InterconnectSystem	Size / Dimension	see
Cable Termination	IDC	Connector - Cable	plug
Termination Style	IDC	1st Contact Gender	Socket (Female)
Color - Connectors	red	Mating Orientation	With
Number of Contacts	6	Contact Termination	:IDC / IDT
Number of Positions	6	Contact Layout, Typical	2.54 [0.100]
Contact Finish Thickness	80µin (2.03µm)	Small Diameter Recovered	No
Wire Gauge or Range - mm2	0.3-0.4Â² [22]	1st Connector Mounting Feature	1x6

Spg	500	Type	IDC Connector
Gender	F	Series	MTA-100
Features	Closed End	Manufacturer	AMP
Product Type	Receptacles / Sockets - Housings	Adapter Series	MTA-100
Connection Type	Wire	Number of Units	1
Tool Type Feature	59803-1	Number of Positions Omitted	None
