284047-8
| Manufacturer | |
| Description | Conn Terminal Block F 8 POS 5.08mm Screw ST Cable Mount 15A/Contact Pluggable Terminal Blocks CONN PLUG 8POS Terminal Block Connectors TERM BLOCK PLUG 8POS 5.08MM Conn Terminal Block F 8 POS 5.08mm Screw ST Cable Mount 15A/Contact Product Highlights:ConnectorType of Connector = Plug (right-hand)Housing Color = GreenSide StackableWithout Screw FlangeSearch Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end TERMI-BLOK VERTICAL PLUG STACK |
| Category |
Business
| Product | Pluggable Terminal Blocks | Product Category | Pluggable Terminal Blocks |
| Standard Package | Bulk | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94 V-0 |
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 300 VAC | Voltage - Supply | 300 |
| Voltage - Rated AC | 300 | Current - Trip (It) | 15 |
| Current Rating (Max) | 15 A | ||
Mechanical
| Color | Green | Pitch | 5.08 mm |
| Packaging | Bulk | Body Color | 绿色 |
| Cable Exit | 侧 | Lead Style | Side |
| Screw Size | M3 | Wire Gauge | 12-30 AWG |
| Termination | Screw | 2nd Connector | 否 |
| Housing Color | Green | Mounting Type | Cable Mount |
| Connector Type | Plug (right-hand) | Contact Finish | Tin |
| Flange Feature | Without | Mounting Style | Through Hole |
| Number of Rows | 1 | Screw Material | Brass |
| Insert Material | 磷青铜 | Plug Wire Entry | 90° |
| Contact Material | Phosphor Bronze | Housing Material | Polyamide (PA) |
| Package Quantity | 100 | Pitch - Connector | Side |
| Termination Style | Screw | Number of Contacts | 8 |
| Number of Positions | 8 | Terminal Block Type | Plug, Female Sockets |
| Terminal Screw Finish | 镍 | Thread/Screw/Hole Size | 黄铜 |
| Center Contact Material | 5.08 [0.200] | Screw Material - Plating | Nickel |
| Wire Gauge or Range - AWG | 30-12 | Wire Gauge or Range - mm2 | 12 |
Product Info
| Type | Terminal Block | Gender | F |
| Features | Retention Latches (Wire Side) | Manufacturer | Buchanan |
| Product Type | Connector | Side Stackable | Yes |
| Number of Levels | 1 | Number of Stages | 不带 |
| Interconnect System | Without | Positions Per Level | 8 |
| Side-by-Side Stacking | 是 | ||
Similar Parts
282825-8
te connectivity / amp
Conn Shrouded Header HDR 8 POS 5.08mm Solder ST Thru-Hole Terminal Block Connectors TERM BLOCK HDR 8POS VERT 5.08MM TE Connectivity 282825 Series 5.08mm Pitch 8 Way 1 Row Straight PCB Header, Solder Termination, 15A Pluggable Terminal Blocks 8 POS SHROUDED HDR Terminal Block Connectors Product Highlights:ConnectorConnector Type = HeaderShroudedHousing Color = GreenSide StackableSearch Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end 8WVERTICALHEADER TE Connectivity Buchanan 系列 5.08mm节距 8路 (1排) 直 印刷电路板接线端子块, 焊接端接, 15A , 通孔 TERMI-BLOK HEADER,ASSY90 8P.5,
282815-8
te connectivity / amp
Conn Shrouded Header HDR 8 POS 5.08mm Solder RA Thru-Hole Pluggable Terminal Blocks TERMI-BLOK HEADER ASSM90 8P.5 Terminal Block Connectors TERM BLOCK HDR 8POS R/A 5.08MM TERMI-BLOK HEADER,ASSY90 8P.5 TERMI-BLOK HEADER,ASSY90 8P.5 Search Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end
796638-8
