207541-7
| Manufacturer | |
| Description | Conn Wire to Board PIN 3 POS 5mm Solder RA Thru-Hole Metrimate Connectors CONN HDR PIN 3 POS METRIMATE AU TE Connectivity 5mm 3 Way 1 Row Right Angle Through Hole Male Multiway Connector Pin & Socket Connectors PIN HDR ASSY 3P Conn Wire to Board PIN 3 POS 5mm Solder RA Thru-Hole Product Highlights:HeaderIn-Line Connector ConfigurationNumber of Positions = 3PinWithout Coaxial SocketSearch Keywords:Power Pin & Socket, Soft Shell, NIC, Network Interface Cards, PC Cards, cabled power, wire to board, wire to panel. wire to wire, IEC 440 V, power, pcb connectors, discrete wire, crimp, Header3waypinrightangleMetrimate TE Connectivity 3路 5mm节距 直角 通孔 公 MMATE PIN HEADER ASSY,3P LF |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Pin & Socket Connectors | Standard Package | Rail / Tube |
| Factory Pack Quantity | 14 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| UL Rating | 已认证, 获得认可 | Leadfree Defin | Not relevant for lead free process |
| UL File Number | E28476 | CSA File Number | LR16455 |
| Standard Number | CSA, UL | RoHSELV Compliance | RoHS compliant / ELV compliant |
| Approval Agency Marking | 是 | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage | 600.0 | Voltage Rating | 600 V ac |
| Voltage - Supply | 600 | Current Rating (Max) | 14 |
| Voltage - Input (Min) | 600VAC | Voltage - Supply (Min) | 600VAC |
Mechanical
| Color | Red | Depth | 17.5 mm |
| Pitch | 5 mm | Width | 17.5 |
| Height | 12.7mm | Length | 36.86 |
| Packaging | Tube | Body Color | 红色 |
| Orientation | 直角 | Termination | Solder |
| Contact Type | Solder Post | Pitch - Post | .197 |
| 2nd Connector | Without | Housing Color | Red |
| Mounting Type | Right Angle | Connector Type | Header |
| Contact Finish | Gold | Mounting Style | Through Hole |
| Number of Rows | 1 | Plating - Body | Tin |
| Shaft Diameter | Without | Connector Usage | In-Line |
| Height (Inches) | 12.7 | Contact Material | Copper Alloy |
| Housing Material | Thermoplastic | Length - Overall | 36.86 mm |
| Mounting Feature | With | Package Quantity | 14 |
| Panel Mount Type | 通孔 - 焊接 | Primary Material | Copper Alloy |
| Termination Rows | 焊接 | Termination Style | 插针 |
| 1st Contact Gender | Pin (Male) | Connector - Sensor | Without |
| Number of Contacts | 3 | Number of Positions | 3 |
| Center Contact Finish | 5.0 | Compatible Shell Size | 插头外壳 |
| Contact Length - Post | 信号（数据） | Mounting Hole Diameter | 带有 |
| Contact Layout, Typical | 同轴 | Termination Post Length | 4.88 |
| Contact Finish Thickness | 30µin (0.76µm) | Contact Material - Mating | Gold (30) |
Product Info
| Type | Wire to Board | Gender | PIN |
| Coded, Keyed | No | Manufacturer | AMP |
| Product Type | Connector | Other Specifications | No |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -55 – 130 °C [ -67 – 266 °F ] | Thermal Resistance of Package | 1.6 mm [ .063 in ] |
