207496-9
| Manufacturer | |
| Description | Conn Power SKT 4 POS 5mm Solder ST Thru-Hole 4 Terminal 1 Port Metrimate Connectors CONN HEADER SKT 4POS VERT GOLD Pin & Socket Connectors 4P SOCKET HEADER GLD METRIMATE 5mm (.197") Centerline, 600 V, 14 A max. (Metrimate) 5mm (.197") Centerline, 600 V, 14 A max. (Metrimate) Product Highlights:HeaderSquare Grid Connector Configuration4 PositionsSocketWithout Coaxial SocketSearch Keywords:Power Pin & Socket, Soft Shell, NIC, Network Interface Cards, PC Cards, cabled power, wire to board, wire to panel. wire to wire, IEC 440 V, power, pcb connectors, discrete wire, crimp, SKT HDR ASSY,4P,MMATE LF |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Pack | 126 | Product Category | Pin & Socket Connectors |
| Standard Package | Bulk | Factory Pack Quantity | 126 |
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 已认证, 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR16455 | Standard Number | CSA, UL |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Approval Agency Marking | 是 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage | 600.0 | Voltage Rating | 600 V |
| Voltage - Supply | 600 | Frequency - Center | 不带 |
| Current Rating (Max) | 14 | ||
Mechanical
| Color | Red | Pitch | 5 mm |
| Width | 15.49 | Length | 22.61 |
| Packaging | Bulk | Shrouding | No |
| Body Color | 红色 | Row Spacing | 0.197" (5.00mm) |
| Termination | Solder | Contact Type | Solder Post |
| Pitch - Post | .197 | 2nd Connector | With |
| Housing Color | Red | Mounting Type | Through Hole |
| Connector Type | Header | Contact Finish | Tin over Nickel |
| Mounting Style | Through Hole | Number of Rows | 2 |
| Plating - Body | Tin | Shaft Diameter | Without |
| Connector Usage | Square Grid | Height (Inches) | 14.35 |
| Locking Feature | Locking Latch | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic - GF | Mounting Feature | With |
| Package Quantity | 126 | Panel Mount Type | 通孔 - 焊接 |
| Primary Material | Phosphor Bronze | Termination Style | 插座 |
| 1st Contact Gender | Socket (Female) | Connector - Sensor | Without |
| Number of Contacts | 4 | Termination Finish | 带有 |
| Number of Positions | 4 | Plating - Thickness | 3.81 |
| Center Contact Finish | 5.0 | Compatible Shell Size | 母端护套 |
| Contact Length - Post | 信号（数据） | Mounting Hole Diameter | 带有 |
| Contact Layout, Typical | 网络 | Termination Post Length | 4.6 |
| Contact Finish Thickness | 30µin (0.76µm) | Contact Material - Mating | Gold (30) |
Product Info
| Type | Power | Gender | SKT |
| Series | Metrimate | Coded, Keyed | No |
| Product Type | Connector | Other Specifications | No |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -55 – 130 °C [ -67 – 266 °F ] | Thermal Resistance of Package | 1.6 mm [ .063 in ] |
