Business
| Product Category | Hard Metric Connectors | Standard Package | Rail / Tube |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Voltage Rating | 250V | Current Rating (Max) | 0.600A |
Mechanical
| Pitch | 2.5 mm | Weight | 0 |
| Packaging | Tube | Termination | Press Fit |
| Pitch - Post | :1.5mm | Mounting Type | Through Hole |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Tin Over Nickel |
| Mounting Style | Through Hole | Number of Rows | 8 |
| Connector Style | High Speed | Connector Usage | Backplane |
| Contact Material | Copper Nickel Silicon Alloy | Housing Material | Polyester |
| Primary Material | Connector | Termination Style | PCB |
| Number of Contacts | 80 | Contact Termination | :Press Fit Right Angle |
| Number of Positions | 120 | Contact Layout, Typical | 80 Single Signal, 40 Ground |
Product Info
| Type | Hard Metric | Gender | :Receptacle |
| Series | Z-Pack | Features | Shielded |
| Manufacturer | Z-PACKSeries | Product Type | Receptacles |
| Number of Columns | 10 | Number of Positions Loaded | All |
Environmental
| Operating Temperature | -65°C ~ 105°C | ||
