206426-1

Business

Lead Time	90 Days	Tradename	CPC Series 3
Subcategory	Connector Circular	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Compliance	No	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Black	Sealed	No
Weight	0.02	Diameter	34.01 mm
Packaging	Bulk	Cable Exit	No
Shell Size	17	Orientation	Keyed
Shell Style	Receptacle	Termination	Crimp
Thread Size	15/16-20 UNEF-2A	Contact Form	3Signal
Contact Size	3 Power	Contact Type	Crimp
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Plug for Male Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Connector Style	Plug	Insertion Angle	:17-3
Material - Body	:Glass Reinforced Nylon (Polyamide)	Material Finish	:-
Contact Material	Copper	Housing Material	Thermoplastic
Length - Overall	41.78 mm	Primary Material	CircularPlasticConnector
Termination Style	Wire	1st Contact Gender	Male
Color - Connectors	:Black	Mating Orientation	Keyed
Number of Contacts	3	Insulation Diameter	5.59 [0.220]
Number of Positions	3	Shell Size - Insert	All Plastic
Shell Material, Finish	Thermoplastic	1st Connector Mounting Type	:Cable
2nd Connector Mounting Feature	Reverse	Shell Size - Insert (Convert To)	17-3

Note	Contacts Not Provided	Type	CPC
Gender	PL	Series	Series 3
Features	ReverseGender	Preloaded	No
Arrangement	17-3	CAD Drawing	3D CAD Model
Manufacturer	Series3	Product Type	Connector
RF Family/Standard	206426	Other Specifications	Without
Application Specifics	Commercial	For Use With/Related Products	Pin Contacts
