Lead Time20 DaysTradenameCPC Series 3
SubcategoryConnector CircularProduct CategoryStandard Circular Connector
Standard PackageBulkFactory Pack Quantity1

Compliance

RoHSLead free / RoHS CompliantEU RoHSCompliant
Tariff No85369010ComplianceNo
Rad HardenedNoLeadfree DefinNot relevant for lead free process
RoHSELV ComplianceRoHS compliant, ELV compliantMaterial Flammability RatingUL 94V-0

Electrical

Voltage Rating:250VVoltage - Working:250V
Number of Channels0Current Rating (Max):25A
Insulation Resistance:5000Mohm

Mechanical

ColorBlackDepth41.53 mm
Height36.45 mmSealedNo
Weight0.022PackagingBulk
Cable ExitNoShell Size17
OrientationKeyedShell StyleReceptacle
TerminationCrimpThread Size15/16-20 UNEF-2A
Contact Size3 PowerContact Type3Power
Housing ColorBlackMounting TypePanel Mount
Angle of ThrowStraightConnector TypeReceptacle for Female Contacts
Fastening TypeThreadedMounting StylePanel
Connector StyleReceptacleInsertion Angle:17-3
Material - Body:Glass Reinforced Nylon (Polyamide)Material Finish:-
Panel Thickness0.125"Contact MaterialCopper
Housing MaterialThermoplasticLength - Overall36.45 mm
Panel Mount TypeSquare FlangePrimary MaterialCircularPlasticConnector
Termination StyleWire1st Contact GenderM
Color - Connectors:BlackMating OrientationKeyed
Number of Contacts3Panel Cutout Shape:29.4mm
Insulation Diameter5.59 [0.220]Number of Positions3
Shell Size - InsertAll PlasticMounting Hole Diameter0.15"
Shell Material, FinishThermoplastic1st Connector Mounting Type:Panel
2nd Connector Mounting FeatureReverseShell Size - Insert (Convert To)17-3

Product Info

NoteContacts Not ProvidedTypeCPC
GenderRCPSeriesSeries 3
FeaturesReverseGenderPreloadedNo
Arrangement17-3CAD Drawing3D CAD Model
ManufacturerSeries3Product TypeConnector
RF Family/Standard206425Other SpecificationsWithout
Application SpecificsCommercialFor Use With/Related ProductsSocket Contacts
