206037-3
| Manufacturer | |
| Description | Conn CPC SKT 16 POS ST Panel Mount 16 Terminal 1 Port Standard Circular Connector CPC PLUG SZ 17-16 PLUG SZ 17-16 CPC Connectors CONN PLUG CPC 16POS FREE HANGING Conn CPC SKT 16 POS ST Panel Mount 16 Terminal 1 Port Product Highlights:ConnectorNumber of Positions = 16PlugFor Use With Socket ContactsNot PreloadedSearch Keywords:Circular Plastic, Cabled Power, POWERBAND, coaxial, power, DIN 57627, III+ contacts, CMC, Metal Shell CPC, TETRASEAL, IEC IP 65, IEC IP 67, input/output, box to box, circular industrial, sealed, discrete wire, crimp, input/output, box to box, circular, Circular Plastic Connectors, CPC CPC PLUG ASSEMBLY SZ 17-16 |
| Category |
Business
| Lead Time | 63 Days | Tradename | CPC Series 1 |
| Subcategory | Connector Circular | Product Category | Standard Circular Connector |
| Standard Package | Bulk | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | Compliance | No |
| Rad Hardened | No | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | UL Flammability Rating | UL 94V-0 |
| Approval Agency Marking | 否 | Material Flammability Rating | UL 94V-0 |
Electrical
| Fluid Resistance | 无 | Number of Channels | 16 |
| Connector - Voltage Input | 标准 | ||
Mechanical
| Sealed | No | Outline | 17 |
| Diameter | 34.27 mm | Packaging | Bulk |
| Shielding | 否 | Body Color | 黑色 |
| Cable Exit | No | Shell Size | 17 |
| Orientation | A | Shell Style | Plug |
| Thread Size | 15/16-20 UNEF-2A | Contact Form | 16Signal |
| Contact Size | 16 | Contact Type | Crimp |
| Housing Color | Black | Mounting Type | Panel Mount |
| Connector Type | Plug for Female Contacts | Fastening Type | Threaded |
| Mounting Style | Free Hanging | Number of Pins | 0 |
| Shell Material | 插头 | Connector Style | Plug |
| Housing Material | Thermoplastic | Length - Overall | 27.43 mm |
| Package Quantity | 100 | Termination Style | Wire |
| 1st Contact Gender | Socket (Female) | Mating Orientation | Threaded |
| Number of Contacts | 16 | Termination Finish | 带有 |
| Number of Positions | 16 | Shell Size - Insert | All Plastic |
| Mounting Hole Diameter | 带有 | Shell Material, Finish | Nylon, Glass Filled |
| 2nd Connector Mounting Feature | Standard | ||
Product Info
| Note | Contacts Not Provided | Type | CPC |
| Gender | PL | Series | CPC |
| Key Type | A | Preloaded | No |
| Product Type | Connectors | RF Family/Standard | 206037 |
| Other Specifications | Without | For Use With/Related Products | Socket Contacts |
Environmental
| Operating Range | 不密封 | ||
