2-644486-8

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	2000

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Leadfree Defin	Wave solder capable to 240Â°C	UL File Number	E28476
CSA File Number	LR7189	Standard Number	CSA, UL
CSA Certification	Certified	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Black	Depth	7.95 mm
Pitch	2.54 mm	Height	10.41 mm
Length	22.45 mm [ .884 in ]	Packaging	Bulk
Shrouding	Yes	Body Color	黑色
Orientation	直	Termination	Solder
Contact Type	Male Pin	Polarization	Polarized Retention Peg
2nd Connector	Without	Contact Shape	Square
Housing Color	White	Mounting Type	Vertical
Connector Type	Header, Shrouded	Contact Finish	Matte Tin
Contact Timing	Without	Fastening Type	Friction Lock
Mounting Style	Through Hole	Number of Rows	1
Plating - Body	Tin	Shell Material	摩擦锁
Connector Usage	Header	Insert Material	铜合金
Contact Material	Copper Alloy	Housing Material	Polyester
Length - Overall	22.45 mm	Mounting Feature	Without
Package Quantity	1000	Panel Mount Type	Without
Size / Dimension	0.64 [.025]	Termination Rows	焊接
Termination Style	Through Hole	1st Contact Gender	Pin (Male)
Mating Orientation	Without	Number of Contacts	8
Termination Finish	不带	Number of Positions	8
Backshell Interrupts	Without	Compatible Shell Size	MTA .100 连接器组件
Contact Length - Post	3.56 mm [ .14 in ]	Mounting Hole Diameter	带有
Contact Finish - Mating	锡	Contact Layout, Typical	同轴
Contact Length - Mating	0.200" (5.08mm)	Contact Material - Post	Copper Alloy
Termination Post Length	5.1 mm [ .2 in ]	Contact Finish Thickness	3.81 – 6.3 µm [ 150 – 250 µin ]
Small Diameter Recovered	No	Static Discharge Shielding	不带
Jacket (Insulation) Thickness	1.27 µm, 50 µin
