147105-7

Manufacturer	TE Connectivity Ltd.
Description	Headers & Wire Housings OBSOLETE .100 inch AMPMODU Receptacles CONN RCPT 14POS DUAL VERT SMD 14 MODIV VRT DR SFMNT 30AU
Category	Resistors and PotentiometersRotary PotentiometersRotary Potentiometers

对参数有疑问？问 AI 助手

Business

Tradename

AMPMODU

Standard Package

250

Compliance

RoHS	Contains lead / RoHS non-compliant	MIL-C-55032	否
Standard Number	CSA LR7189, UL E28476	Material Flammability Rating	UL 94V-0

Electrical

Resistance - Input	5000	Voltage - Clamping	750
Voltage - Rated AC	250	Connector Impedance	不带
Resistance @ 25degC	12	Current Rating (Max)	2

Mechanical

Color	Black	Pitch	0.100" (2.54mm)
Height	6.73 mm [ .265 in ]	Packaging	Tape & Reel (TR)
Body Color	黑色	Row Spacing	0.100" (2.54mm)
Termination	Solder	Contact Type	Female Socket
Mounting Type	Surface Mount	Connector Type	Receptacle, Bottom or Top Entry
Contact Finish	Gold	Mounting Style	标准
Number of Rows	2	Pressure (PSI)	标准
Terminal Style	单叉	Connector Usage	底部或顶部, 闭合入口
Insert Material	磷青铜	Housing Material	聚酯 - GF
Package Quantity	250	Panel Mount Type	表面贴装
Termination Style	插座	Number of Positions	14
Bushing, Grommet Type	不带	Compatible Shell Size	与接头配合
Termination Post Length	1.04 mm [ .041 in ]	Contact Finish Thickness	30µin (0.76µm)

Product Info

Note	为了获得最小接合柱长度，在最大触点尺寸上增加 .51 [.020]（不包含斜面上的柱引线）。, 贴装与 Kapton 圆点兼容。	Series	AMPMODU MOD IV
Sealable	否	Stackable	是
Product Type	Receptacles / Sockets - PCB	Assembly Configuration	板支座
Number of Positions Loaded	All

Environmental

Mechanical Life	Obsolete	Temperature - Test	是
Operating Temperature	-65 – 125	Thermal Resistance of Package	1.4 – 2.4 mm [ .055 – .094 in ]
