Product CategoryHeaders & Wire HousingsStandard PackageBulk
Factory Pack Quantity1

Compliance

RoHSLead free / RoHS CompliantTariff No85411000
Leadfree DefinNot relevant for lead free processApproval AgencyCSA,UL
RoHSELV ComplianceRoHS compliant, ELV compliantMaterial Flammability RatingUL 94V-0

Electrical

Current Rating (Max)4/Contact AVoltage - Supply (Min)250VAC

Mechanical

ColorWhiteDepth12.95mm
Pitch2.54 mmWidth6.6mm
Height6.6 mmLength8.13mm
Weight0.00023PackagingBulk
ShroudingNoCable Exit180°
Wire Gauge22-28 AWGContact TypeFemale Socket
2nd ConnectorWithHousing ColorWhite
Mounting TypeStraightAngle of ThrowStraight
Connector TypeCrimpContact Finish2.54 [0.100]
Fastening TypeLocking RampMounting StyleWire
Number of Rows1Connector UsageReceptacle
Housing MaterialPolymerLength - Overall8.13 mm
Mounting FeatureWithoutPanel Mount TypeWithout
Primary MaterialInterconnectSystemPin Hole Diameter0.1"
Termination StyleCrimp1st Contact GenderSocket (Female)
Mating OrientationWithNumber of Contacts3
Contact TerminationCrimpNumber of Positions3

Product Info

NoteNot interchangeable with CST-100 contacts and housings.; Mates with all MTA-100TypeHousing
GenderRCPSeriesCST-100
CAD Drawing3D CAD ModelManufacturerAMP
Product TypeCST-100 II HousingsApplication SpecificsWire-to-Board
For Use With/Related ProductsCenterline Economy Power Connector

Environmental

Operating Temperature-55C to 105C

Documents & Media

Online Document

Sourcing & traceability

Datasheet
1375820-3
