103164-2
| Manufacturer | |
| Description | Conn Shrouded Header HDR 8 POS 2.54mm Solder RA Thru-Hole .100 inch AMPMODU Headers CONN HEADER .100 8POS R/A SHRD Headers & Wire Housings 08 MODII HDR DRRA 3/4SHRD .100 .100 inch AMPMODU Headers Product Highlights:HeaderHeader Type = StandardNumber of Rows = DualNumber of Positions = 8Mating Post Length = 8.08 mmSearch Keywords:board to board, AMPMODU, pcb connectors, 08 MODII HDR DRRA 3/4SHRD .100 |
| Category |
Business
| Tradename | AMPMODU | Standard Pack | 184 |
| Product Category | Headers & Wire Housings | Standard Package | Trays |
| Factory Pack Quantity | 184 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current Rating (Max) | 3 A | Insulation Resistance | 5000 MOhms |
| Voltage - Protection Rating (VPR) | 750 Vrms | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Base Type | 不带 | Lock Type | 不带 |
| Packaging | Tray | Body Color | 黑色 |
| Lead Style | 正方形 | Stabilizer | 不带 |
| Row Spacing | 0.100" (2.54mm) | Termination | Solder |
| Contact Type | Male Pin | 1st Connector | 否 |
| Mounting Type | Through Hole, Right Angle | Connector Type | Header, Shrouded |
| Contact Finish | Gold Over Nickel | Fastening Type | Detent Lock |
| Mounting Style | 标准 | Number of Rows | 2 |
| Shell Material | 3- 面 | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Housing Material | Thermoplastic |
| Package Quantity | 184 | Panel Mount Type | 通孔 |
| Termination Style | Through Hole | 1st Connector Type | 带罩 |
| 1st Contact Gender | Pin (Male) | Diameter - Outside | .64 mm [ .025 in ] |
| Number of Contacts | 8 | Termination Finish | 带有 |
| Number of Positions | 8 | Length - Post (Mating) | 8.08 mm |
| Mounting Hole Diameter | 带有 | Contact Length - Mating | 0.318" (8.08mm) |
| Termination Post Length | 3.18 mm | Contact Finish Thickness | 30µin (0.76µm) |
| Static Discharge Shielding | 不带 | Shell Size, Connector Layout | 1.676 mm [ .066 in ] |
| 1st Connector Mounting Feature | 否 | ||
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | AMPMODU MOD II | Key Type | 否 |
| Product Type | Headers | Number of Positions Loaded | All |
Environmental
| Seal Rating | 不带 | Ingress Protection | 带罩 |
| Operating Temperature | - 55 C to + 125 C | Thermal Resistance of Package | 1.397 mm [ .055 in ] |
| Operating Temperature - Junction | 否 | ||
