102394-8
| Manufacturer | |
| Description | Conn Housing RCP 20 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts 20 AMP MODU MT HSG DR .100CL Headers & Wire Housings 20 HSG DR .100CL Conn Housing RCP 20 POS 2.54mm IDT ST Cable Mount Search Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE |
| Category |
Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Trays | Factory Pack Quantity | 120 |
Compliance
| RoHS | Lead free / RoHS Compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage - Supply | 250 VAC | Contact Resistance | 15 mΩ |
| Resistance - Input | 5000 | Connector Impedance | 刺破式压接 (IDC) |
| Current Rating (Max) | 3 A | Voltage - Protection Rating (VPR) | 600 V |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.1 mm [ .24 in ] | Length | 25.4 mm [ 1 in ] |
| Lock Type | 不带 | Packaging | Bulk |
| Body Color | 黑色 | Wire Gauge | 20-30 AWG |
| Row Spacing | 0.100" (2.54mm) | Contact Type | Female Socket |
| Mounting Type | Straight | Connector Type | Receptacle |
| Mounting Style | Wire | Number of Rows | 2 |
| Housing Material | Thermoplastic | Package Quantity | 120 |
| Termination Style | IDC | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 20 | Contact Termination | IDC |
| Number of Positions | 20 | Compatible Shell Size | 连接器 |
| Mounting Hole Diameter | 不带 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | AMPMODU MT |
| Product Type | Receptacles / Sockets - Housings | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | - 65 C to + 105 C |
Documents & Media
