102241-7

Manufacturer	TE Connectivity Ltd.
Description	Conn Housing RCP 9 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 9POS .100 POLAR RECEPTACLE, AMPMODU, MOD IV, 9 POSITION Headers & Wire Housings POLARIZED HSG 9 SNGL detent latching Conn Housing RCP 9 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 9Housing Type = ReceptacleNumber of Rows = SingleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE CONNECTOR, RECEPTACLE, 2.54MM, 9WAY RECEPTACLE,AMPMODU,MODIV,9POSITION,.100IN,SINGLEROW,LATCHED 09 MODIV HSG COMP SR .100 POL
Category	Connector SolutionsCrimp & Solder Terminals / SplicesCrimp Terminals

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	1

Compliance

RoHS

Contains lead / RoHS non-compliant

Tariff No

85369010

Electrical

Range deg/s	:TE - AMPMODU Mod IV Series	Voltage Rating	250 VAC
Switch Function	Detent Latching	Current Rating (Max)	3 A

Mechanical

Color	Black	Pitch	2.54 mm
Weight	0.00001	Packaging	Bulk
Wire Gauge	20-32 AWG	Contact Type	Female Socket
Mounting Type	Straight	Connector Type	Receptacle
Contact Finish	:-	Fastening Type	Locking Ramp
Number of Rows	1	Contact Material	:-
Housing Material	Nylon	Primary Material	InterconnectSystem
Number of Contacts	9	Contact Termination	Crimp
Number of Positions	9

Product Info

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Series	AMPMODU/MOD IV
Manufacturer	AMPMODU/MODIVSeries	Product Type	Wire Housings

Environmental

Operating Temperature

- 65 C to + 105 C

Documents & Media

PDF Document

580372.pdf

Online Document

102241-7?RQPN=102241-7
