102202-5
| Manufacturer | |
| Description | Conn Shrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole .100 inch AMPMODU Headers CONN HEADER VERT .100 8POS 15AU Headers & Wire Housings SHROUDED VERT SNGL 8 with standoffs Conn Shrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole Product Highlights:HeaderHeader Type = ShroudedNumber of Rows = SingleNumber of Positions = 8Mating Post Length = 6.10 mmSearch Keywords:board to board, AMPMODU, pcb connectors, Header,ThroughHole;Shrouded;Vertical;CopperAlloy;Thermoplastic;8;3A 08 MODII HDR SRST SHRD .100CL |
| Category |
Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Rail / Tube | Factory Pack Quantity | 92 |
Compliance
| RoHS | Contains lead / RoHS non-compliant | Standards | ULListed,CSACertified |
| Approval Agency | CSA,UL | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current Rating (Max) | 3 A | Insulation Resistance | 5000 MOhms |
| Voltage - Switching DC | 750V | Voltage - Protection Rating (VPR) | 750 Vrms |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Base Type | 带有 | Lock Type | 不带 |
| Packaging | Tube | Port Size | 0.025in. |
| Body Color | 黑色 | Lead Style | 正方形 |
| Stabilizer | 不带 | Row Spacing | 2.54 mm |
| Termination | Solder | Contact Type | Male Pin |
| Length - Pin | 0.13" | 1st Connector | 否 |
| Mounting Type | Through Hole | Angle of Throw | Straight |
| Connector Type | Header, Shrouded | Contact Finish | Gold Over Nickel |
| Mounting Style | 标准 | Number of Rows | 1 |
| Shell Material | 4- 面 | Insert Material | 黄铜 |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Length - Overall | 0.92" | Package Quantity | 23 |
| Panel Mount Type | 通孔 | Primary Material | InterconnectSystem |
| Pin Hole Diameter | 0.1" | Termination Style | Through Hole |
| 1st Connector Type | 带罩 | 1st Contact Gender | Pin (Male) |
| Diameter - Outside | .64 mm [ .025 in ] | Number of Contacts | 8 |
| Termination Finish | 带有 | Contact Termination | Tin-LeadoverNickel |
| Number of Positions | 8 | Contact Mating Finish | Gold(15) |
| Length - Post (Mating) | 6.1 mm | Mounting Hole Diameter | 0.035" |
| Contact Length - Mating | 0.240" (6.10mm) | Termination Post Length | 3.3 mm |
| Contact Finish Thickness | 15µin (0.38µm) | Static Discharge Shielding | 不带 |
| Shell Size, Connector Layout | 1.778 mm [ .07 in ] | 1st Connector Mounting Feature | 否 |
| Contact Finish - Post (Mating) | 哑光 | ||
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | AMPMODU MOD II | Features | Breakaway |
| Key Type | 否 | Manufacturer | AMPMODU |
| Product Type | Headers | Matrix (Columns x Rows) | 0.1in. |
| Number of Positions Loaded | All | ||
Environmental
| Seal Rating | 不带 | Ingress Protection | 带罩 |
| Operating Temperature | - 55 C to + 105 C | Thermal Resistance of Package | 1.397 mm [ .055 in ] |
| Operating Temperature - Junction | 否 | ||
