1-86177-4
| Manufacturer | |
| Description | Conn Housing RCP 14 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 14POS .100 DUAL ROW Headers & Wire Housings 14 HSG COMP DR .100CL Conn Housing RCP 14 POS 2.54mm Crimp ST Cable Mount Product Highlights:ConnectorHousingConnector Style = ReceptacleContact Type = Receptacle2.54 mm CenterlineSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 14 MODIV HSG COMP DR .100CL |
| Category |
Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 VAC | Voltage - Supply | 250 VAC |
| Contact Resistance | 12 mΩ | Resistance - Input | 5000 |
| Connector Impedance | 压接 | Current Rating (Max) | 3 A |
| Voltage - Protection Rating (VPR) | 750 V | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.1 mm [ .24 in ] | Length | 17.77 mm [ .7 in ] |
| Lock Type | 不带 | Packaging | Bulk |
| Body Color | 黑色 | Row Spacing | 0.100" (2.54mm) |
| Contact Type | Female Socket | Mounting Type | Straight |
| Connector Type | Receptacle | Mounting Style | Wire |
| Number of Rows | 2 | Insert Material | 磷青铜 |
| Housing Material | Nylon | Package Quantity | 1 |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 14 | Contact Termination | Crimp |
| Number of Positions | 14 | Compatible Shell Size | 公端 |
| Mounting Hole Diameter | 不带 | Static Discharge Shielding | 不带 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | AMPMODU MOD IV |
| Product Type | Receptacles / Sockets - Housings | Other Specifications | 否 |
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | -65 – 105 |
