1-643814-8
| Manufacturer | |
| Description | Conn IDC Connector F 18 POS 2.54mm IDT RA Cable Mount Loose Piece MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RECEPT 18POS 24AWG MTA-100 Headers & Wire Housings 18P MTA100 CONN ASSY POL RIB Conn IDC Connector F 18 POS 2.54mm IDT RA Cable Mount Loose Piece Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 18P MTA100 CONN ASSY POL RIB |
| Category |
Business
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | UL Rating | 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | RoHSELV Compliance | Not ELV/RoHS compliant |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 VAC | Voltage - Supply | 250 |
| Voltage - Rated AC | 250 | Connector Impedance | IDC |
| Current Rating (Max) | 5 A | ||
Mechanical
| Color | White | Pitch | 2.54 mm |
| Length | 45.72 | Packaging | Bulk |
| Shrouding | No | Wire Type | Discrete or Ribbon Cable |
| Body Color | 白色 | Cable Exit | 90° |
| Cable Type | 分离式导线, 绞线 | Wire Gauge | 24 AWG |
| Termination | IDT | Contact Type | Female Socket |
| Polarization | Polarizing Tab | 2nd Connector | With |
| Housing Color | White | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Closed End | Contact Finish | Tin-Lead Over Nickel |
| Contact Timing | Without | Fastening Type | Locking Ramp |
| Mounting Style | Wire | Number of Rows | 1 |
| Shell Material | 标准 | Connector Usage | Receptacle |
| Height (Inches) | 6.99 | Insert Material | 铜合金 |
| Contact Material | Copper Alloy | Housing Material | Nylon |
| Mounting Feature | Without | Package Quantity | Loose Piece |
| Panel Mount Type | Without | Cable Termination | IDC |
| Termination Style | IDC | 1st Contact Gender | Socket (Female) |
| Mating Orientation | With | Number of Contacts | 18 |
| Termination Finish | 带有 | Contact Termination | Locking Lance |
| Insulation Diameter | 1.52 mm [ .06 in ] | Number of Positions | 18 |
| Compatible Shell Size | MTA .100 头 | Contact Length - Post | 电源 |
| Mounting Hole Diameter | 带有 | Contact Finish - Mating | 锡铅 |
| Contact Layout, Typical | 2.54 [0.100] | Surface Mount Land Size | Without |
| Contact Finish Thickness | 80µin (2.03µm) | Small Diameter Recovered | No |
| Wire Gauge or Range - mm2 | 0.2² [24] | Static Discharge Shielding | 带有 |
Product Info
| Type | IDC Connector | Gender | F |
| Series | MTA-100 | Features | Closed End |
| Sealable | 否 | Manufacturer | AMP |
| Product Type | MTA-100 Connectors | Connection Type | Wire |
| Number of Positions Omitted | None | ||
Environmental
| Operating Temperature | -55 – 105 °C [ -67 – 221 °F ] | ||
Documents & Media
Similar Parts
1-643075-8
te connectivity / amp
Connector Accessories 18 POS Strain Relief Closed End Covers Nylon White MTA, CST and SL Accessories CONN COVER STRAIN RELIEF 18POS Headers & Wire Housings 18P STR/REL CVR 1-643075-8 Connector Accessories 18 POS Strain Relief Closed End Covers Nylon White Product Highlights:Strain Relief CoversWithout Panel AttachmentCover Style = Closed EndNumber of Positions = 18Used For MTA-100 ConnectorsSearch Keywords:Keying plug type, PCB, Wire-to-Board, .050 Centerline, IDC, Discrete Wire Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, PWRSIGALLP 18PMTA100MOLDEDCOVER 18P MTA100 MOLDED COVER
1-641215-8
te connectivity / amp
Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 18POS .100 30AU Headers & Wire Housings FRICTION LCK HDR 18P MTA, CST-100 II, MT-6 and SL Connectors and Headers Product Highlights:MTA-100 ConnectorsNumber of Positions = 18Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 18P MTA100 HDR ASSY FL/ST 30AU
58246-1
te connectivity / amp
Connector Accessories MTA100 Receptacle Connector Terminating Head Crimpers .100 INTRCHNG HEAD CLOSED END HEAD ASSEM TOOL FOR MTA-100 RECP AMP MTA termination head,0.1in pitch TOOL, RECEPTACLE HEAD, 0.1" AMP;HEADFORMTA-100 Head; Series: MTA-100; Size:22 AWG,24 AWG,26 AWG,28 AWG Mounting tool for MTA-100, 58246-1, TE Connectivity TE Connectivity MTA-100 系列 端接工具头部
647306-7
te connectivity / amp
Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER 18POS VERT .100 TIN Headers & Wire Housings 18P MTA100 HDR ASSY F/L,W/O#10 Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 18P MTA100 HDR ASSY F/L,W/O#10
1-640550-8
te connectivity / amp
Connector Accessories 18 POS Closed End Dust Cover Polyester White MTA, CST and SL Accessories CONN DUST COVER 18POS MTA-100 18P MTA100 COVER Headers & Wire Housings 18P COVER 18P MTA100 COVER Search Keywords:Keying plug type, PCB, Wire-to-Board, .050 Centerline, IDC, Discrete Wire Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, PWRSIGALLP 18PMTA100COVER
1-641122-8
te connectivity / amp
Conn Unshrouded Header HDR 18 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER 18POS VERT GOLD
58246-2
te connectivity / amp
Connector Accessories Terminating Head TOOL HEAD TERM MTA 100 W/O TL Hand Tools HEAD (IDC) MTA 100 W Headers & Wire Housings HEAD (IDC) MTA 100 W
