1-480710-2
| Manufacturer | |
| Description | Conn Housing PL 15 POS 6.35mm Crimp ST Cable Mount Individual .250" Centerline, 600 V, 19 - 36 A max CONN U-MNL PLUG 15POS 94V-2 RED Pin & Socket Connectors 15P PLUG HSG RD Conn Housing PL 15 POS 6.35mm Crimp ST Cable Mount Individual Product Highlights:ConnectorUniversal MATE-N-LOK Product LineHousingHousing Gender = PlugNot PreloadedSearch Keywords:wire to wire, wire to board, Lighting Interconnection, soft shell, pcb connectors, power, discrete wire, crimp, PWRSIGALLP 15P UMNL PLUG HSG RED |
| Category |
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | CSA File Number | LR7189 |
| Standard Number | CSA, UL | CSA Certification | Certified |
| UL Flammability Rating | UL 94V-2 | Approval Agency Marking | 是 |
Electrical
| Voltage - Supply | 600 | ||
Mechanical
| Color | Red | Pitch | 6.35 mm |
| Sealed | Not Sealed | Packaging | Bulk |
| Body Color | 红色 | Wire Gauge | 10-30 AWG |
| Row Spacing | 0.250" (6.35mm) | Contact Type | Male or Female |
| Mounting Type | Straight | Connector Type | Plug |
| Contact Finish | Without | Fastening Type | Latch Lock |
| Number of Rows | 3 | Package / Case | Plug |
| Height (Inches) | 27.43 | Housing Material | 尼龙 |
| Package Quantity | 1 | Number of Contacts | 15 |
| Contact Termination | Crimp | Number of Positions | 15 |
| Compatible Shell Size | 适当的通用 MATE-N-LOK 母端或公端 | Contact Layout, Typical | 矩阵 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Product Type | Receptacle Housings |
| Assembly Configuration | Without | ||
Environmental
| Temperature - Test | 标准件 - 非灼热丝 | Operating Temperature | -55 – 125 °C [ -67 – 257 °F ] |
