STEVAL-ISA043V1
| Manufacturer | |
| Description | Evaluation Board For 1.5 A/1.2 V HighFrequency Synchronous Buck Converter Power Management IC Development Tools 1.5A / 1.2V HI FREQ SYNC BUCK CONVERTER BOARD EVAL BASED ON ST1S06 Development Kit, Power Management With Demonstration Board, Soft Starter Control Block 1.5A/1.2VBUCKCONVERTER STMicroelectronics |
| Category |
Business
| Product | Power Management Modules | Product Category | Power Management IC Development Tools |
| Standard Package | Bulk | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage Rating | 5.5 V | Current - Output | 1.5A |
| Regulator Topology | Buck | Frequency - Switching | 1.5MHz |
| Voltage - Input (Min) | 1.2V | ||
Mechanical
| Packaging | Bulk | Board Thickness | Fully Populated |
Product Info
| Type | Development Kit | Contents | Board |
| Function | High frequency synchronous buck converter demonstration board | Technology | Power Management |
| Kit Contents | Demonstration Board, Soft Starter Control Block | Main Purpose | DC/DC, Step Down |
| Card Standard | Development Kit | Outputs and Type | 1, Non-Isolated |
| Tool Type Feature | ST1S06 | Utilized IC / Part | ST1S06 |
