STEVAL-ISA010V1
| Manufacturer | |
| Description | Ultra Wide Range Dual Output Back Converter Demonstration Board Based On The Viper16 Power Management IC Development Tools Viper16L Wide Range Converter Board BOARD EVAL BASED ON VIPER16 VIPER16, BUCK CONV, SMPS, DEV BOARD |
| Category |
Business
| Product | Power Management Modules | Product Category | Power Management IC Development Tools |
| Standard Package | Boxed | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 84733020 |
Electrical
| Power - Output | 2.55W | Voltage Rating | 85 VAC to 500 VAC |
| Current - Output | 150mA, 100mA | Number of Elements | :Viper16 |
| Regulator Topology | Buck | Frequency - Switching | 60kHz |
| Voltage - Input (Min) | 12V, 5V | ||
Mechanical
| Weight | 0.002 | Packaging | Bulk |
| Board Thickness | Fully Populated | Size / Dimension | 27 mm x 45 mm |
Product Info
| Type | Development Kit | DELETED | Compliant |
| Contents | Board | Features | :Short-Circuit Protection, Standby Voltage of 96mW at 230V Acand Input Voltage of 85 to 500V AC |
| Kit Type | :Power Management | Kit Contents | :Demo Board VIPER16 |
| Main Purpose | AC/DC, Primary Side | Outputs and Type | 2, Non-Isolated |
| Tool Type Feature | VIPER16 | Utilized IC / Part | VIPer16 |
| Chipset Manufacturer | :STMicroelectronics | Application Specifics | :SMPS |
Documents & Media
Similar Parts
VIPER16LD
stmicroelectronics
Off Line Converter 16-Pin SO N Tube AC to DC Switching Converter Off-Line Switcher 54kHz to 66kHz 16-Pin SO N SMPS SO-16 SMD IC OFFLINE CONV PWM OTP 16-SOIC VIPER16LD, Switching Regulator,, 16-Pin SO N AC/DC Converters FIXED FREQ VIPER AC/DC CONVERTER, 800V, 60KHZ, 16SOIC FIXEDFREQ.PDIP7 STMicroelectronics 开关稳压器, 16针 SOIC封装
VIPER16HN
