L6226Q

Manufacturer	STMicroelectronics N.V.
Description	MOSFET DRVR 2.8A 4-OUT Hi/Lo Side Full Brdg 32-Pin VFQFPN Tube 2xH-Br 1.4A 52V QFN5x5 SMD IC MOTOR DRIVER PAR 32VFQFPN Gate Drivers DMOS Full Bridge Driver MOTOR DRIVER, DUAL, DMOS, 2.8A, 32QFN STMicroelectronics 电机驱动器 IC , 用于有刷直流电机, 1.4A, 100kHz, 8 → 52 V
Category	Integrated CircuitsPower Management ICsPower Management ICs

对参数有疑问？问 AI 助手

Business

MOQ	2940	Product	H-Bridge Drivers
Unit Pack	490	Product Category	Gate Drivers
Standard Package	Trays	Standard Package Name	QFN

Compliance

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85423990
Automotive	NO	Rad Hardened	No
Leadfree Defin	RoHS-conform

Electrical

Fall Time	250 ns	Frequency	0.1 MHz
Interface	Parallel	Voltage - Max	5V
Voltage - Load	8 V ~ 52 V	Voltage Rating	8 V
Delay Time - ON	1900(Typ) ns	Frequency - Max	0.1 MHz
Rise Time (Typ)	250 ns	Current - Output	1.4A
Delay Time - OFF	1000 ns	Driver Circuitry	High and Low Side
Voltage - Supply	8 V ~ 52 V	Number of Outputs	4
Current - Output 1	1.4A	Current - Peak Output	2.8 A
Voltage - Input (Min)	8V	Voltage - Supply (Min)	52 V
Input Logic Level - Low	CMOS/TTL	Input Logic Level - High	CMOS\|TTL
On-State Resistance (Max)	730mOhm	Max Propagation Delay @ V, Max CL	250

Mechanical

Weight	0.0069	Packaging	Tube
Case Color	:QFN	Motor Type	:Full Bridge
Mounting Type	Surface Mount	Mounting Style	SMD/SMT
Number of Pins	:32	Package / Case	32VFQFPN
Package Cooled	VFQFPN	Material Finish	:MSL 3 - 168 hours
Package Quantity	VFQFPN	Number of Positions	32
Supplier Device Package	32-VFQFPN Exposed Pad (5x5)

Product Info

Type	2xH-Br	Function	Driver - Fully Integrated, Control and Power Stage
Matchcode	L6226Q	Applications	General Purpose
Number of Drivers	2	Standard Leadtime	12 weeks
Motor Type - AC, DC	Full Bridge	Motor Type - Stepper	Bipolar
Output Configuration	Full H-Bridge, (1) Single

Environmental

Temperature - Test	-25°C	Operating Temperature	-40 to 150 °C
Maximum Temperature Limit	150°C

Documents & Media

PDF Document

CD00182759.pdf

PDF Document

L6226Q
