20SVP47M
| Manufacturer | |
| Description | Sanyo 47μF ±20% 0.045Ω 20V dc SMD Aluminium Electrolytic Capacitor CAPACITOR, 47UF, 20V |
| Category |
对参数有疑问？问 AI 助手
Compliance
| Tariff No | 85322200 | ||
Electrical
| Voltage | 20 V dc | Tolerance | ±20% |
| Capacitance | 47µF | Range deg/s | :SANYO - SVP Series |
| Voltage Rating | :20V | Current - Leakage | 188 μA |
| Capacitance - Input | :Radial Can - SMD | Resistance Tolerance | -20% |
| Ripple Current @ Low Frequency | :1890mA | Ripple Current @ High Frequency | 1890mA |
| ESR (Equivalent Series Resistance) | 0.045Ω | ||
Mechanical
| Depth | :8.3mm | Width | :8.3mm |
| Height | 6.9mm | Length | :6.9mm |
| Weight | 0.008 | Diameter | 8mm |
| Packaging | :Cut Tape | Construction | Cylindrical |
| Mounting Type | Surface Mount | Size / Dimension | 8 Dia. x 6.9mm |
Product Info
| Series | :SVP | Electrical Life | 2000h |
Environmental
| Rated Life | :2000 hours @ 105°C | Operating Temperature | +105°C |
