TNY376PN
| Manufacturer | |
| Description | Line Switcher 7-Pin PDIP-C 17 W (85-265 VAC) 22 W (230 VAC) IC OFFLINE SWIT OVP OTP HV 8DIP AC/DC Converters 17 W 85-265 VAC 22 W 230 VAC Analog switch; DIP8 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 596-1143-5 | Product Category | AC/DC Converters |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Frequency | 264kHz | Output Power | 22 W |
| Power (Watts) | 22W | Power - Rated | 10W |
| Voltage - Max | 700V | Voltage Rating | 700 V |
| Frequency Range | 132kHz ~ 280kHz | Current - Output | 800 mA |
| Duty Cycle (Max) | 65 % | Output Isolation | Isolated |
| Voltage - Supply | - 0.3 V | Voltage - Breakdown | 700V |
| Frequency - Switching | 264 kHz | On-State Resistance (Max) | 14Ω |
Mechanical
| Weight | 4.15 g | Packaging | Tube |
| Mounting Type | THT | Mounting Style | Through Hole |
| Package / Case | 7PDIP-C | Package Quantity | 2 |
| Supplier Device Package | DIP-8C | ||
Product Info
| Spg | 2 | Type | Off Line Switcher |
| Number of Units | 1 | ||
Environmental
| Operating Temperature | -40 to 150 °C | ||
