RDK-239
| Manufacturer | |
| Description | REFERENCE DESIGN REPORT FOR A 150 W LLC HIGH-VOLTAGE DC-DC R BOARD EVAL FOR LCS702HG |
| Category |
Business
| Standard Package | 1 | ||
Electrical
| Power - Output | 150W | Current - Output | 6.25A |
| Regulator Topology | Resonant | Voltage - Input (Min) | 24V |
Mechanical
| Board Thickness | Fully Populated | ||
Product Info
| Contents | Board | Main Purpose | DC/DC, Step Down |
| Outputs and Type | 1, Isolated | Utilized IC / Part | LCS702HG |
