LCS702HG
| Manufacturer | |
| Description | INTEGRATED LLC CONTROLLER, HIGH-VOLTAGE POWER MOSFETS AND DR IC LLC CTRL MFET 220W ESIP16C Gate Drivers 220W HV CONTROLLER MOSFET LLC CONTROLLER, 220W, 1MHZ, 16SIP 交直流转换器, -1.3 → 530 V, 13引脚 eSIP-16J封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Half-Bridge Drivers | Other Names | 596-1433-5 |
| Standard Package | 30 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423990 | ||
Electrical
| Input Type | Non-Inverting | Current - Output | 8.3 A |
| Voltage - Supply | 11.4 V ~ 15 V | Number of Outputs | 2 |
| Current - Peak Output | 8.3A | On-State Resistance (Max) | 740 mOhm |
Mechanical
| Weight | 0.000638 | Packaging | Tube |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Number of Pins | :16 | Package / Case | 16-SIP, 13 Leads, Exposed Pad, Formed Leads |
| Material Finish | :- | Supplier Device Package | 16-PESIP |
Product Info
| Type | High Side/Low Side Driver | Features | :- |
| Function | :Half Bridge LLC Resonant Control IC for Lighting | ||
Environmental
| Operating Temperature | 0°C ~ 100°C | ||
