1881545
| Manufacturer | |
| Description | Pluggable Terminal Blocks 12P 2.5mm 90 DEG Conn Shrouded Header HDR 12 POS 2.5mm Solder RA Thru-Hole TERM BLOCK HDR 12POS R/A 2.5MM Header for PCB plug connector MC 0,5/12-G-2,5 Conn;TermBlk;PCB;Header;SnglLvl;90DegAngl;Sldr;12Pole;2.5mmPitch;COMBICON |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Tradename | COMBICON Control |
| Product Category | Pluggable Terminal Blocks | Standard Package | 50 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Standards | EN-VDE,ULRecognized,cULListed | Approval Agency | UL,CUL |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 4A | Voltage | 125V |
| Voltage Rating | 32 V | Number of Poles | 12Poles |
| Current - Output | 4A | Voltage - Nominal | 80V |
| Current Rating (Max) | 4 A | Voltage - Input (Min) | 160V |
| Voltage - Supply (Min) | 80V | Voltage - Protection Level (VP) (2416) | 1.5kV |
Mechanical
| Color | Green | Depth | 10.1 mm |
| Pitch | 2.5 mm | Height | 8.1 mm |
| Length | 10.1 mm | Weight | 0.083952 oz |
| Packaging | Bulk | Lead Style | 90 Deg |
| Termination | Solder | Hole Diameter | 1.2mm |
| Housing Color | Green | Mounting Type | 90 Deg |
| Contact Finish | Tin | Mounting Style | Through Hole |
| Number of Rows | 1 | Housing Material | Polyamide |
| Length - Overall | 31.9 mm | Primary Material | PCB |
| Size / Dimension | 27.5mm | Pin Hole Diameter | 2.5mm |
| Termination Style | Through Hole | Header Orientation | 90°, Right Angle |
| Number of Contacts | 12 | Number of Positions | 12 |
| Terminal Block Type | Header, Male Pins, Shrouded (4 Side) | Material - Insulation | PA |
| Pin Size - Below Flange | 0.8x0.8mm | Wire Gauge or Range - AWG | 26-20 |
Product Info
| Type | Wire to Board | Level | SingleLevel |
| Gender | HDR | Series | MC |
| Features | 90Deg | Manufacturer | COMBICON |
| Number of Levels | 1 | Base Product Number | MC0.5/12-G-2.5 |
| Positions Per Level | 12 | ||
