1768888
| Manufacturer | |
| Description | Pluggable Terminal Blocks SMSTB 2.5/15-ST Conn Terminal Block F 15 POS 5mm Screw Cable Mount 12A TERM BLOCK PLUG 15POS 225DEG 5MM Printed-circuit board connector SMSTB 2,5/15-ST SMSTB25/15-ST Phoenix Contact COMBICON SMSTB 系列 5mm 节距 15 路 母 绿色 插头, 螺钉端接 |
| Category |
Business
| Product | Plugs | Lead Time | 20 Days |
| Tradename | COMBICON Control | Other Names | SMSTB2,5/15-ST |
| Subcategory | Connector Terminal Blocks | Product Category | Pluggable Terminal Blocks |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-2 | ||
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 250 V | Current Rating (Max) | 12 A |
| Voltage - Input (Min) | 320V | ||
Mechanical
| Color | Green | Depth | 25.6 |
| Pitch | 0.197" (5.00mm) | Height | 15.5 mm |
| Weight | 1 lb | Material | 聚酰胺，镀锡 |
| Packaging | Bulk | Wire Gauge | 12-30 AWG |
| Termination | Screw | Mounting Type | Cable Mount |
| Connector Type | 母座 | Contact Finish | Tin |
| Number of Rows | 1 | Plug Wire Entry | 225° |
| Housing Material | Polyamide | Length - Overall | 75 |
| Termination Rows | 螺钉 | Termination Style | Screw |
| Number of Contacts | 15 | Number of Positions | 15 |
| Terminal Block Type | Plug, Female Sockets | Wire Gauge or Range - AWG | 24-12 |
Product Info
| Type | Terminal Block | Gender | F |
| Series | SMSTB | Features | Retention Latches (Non-Wire Side) |
| Industry Aliases | SMSTB 2, 5/15-ST | Number of Levels | 1 |
| Positions Per Level | 15 | ||
