点击放大查看
1754698
| Manufacturer | |
| Description | Pluggable Terminal Blocks MSTB 2 5/15-G Conn Shrouded Header HDR 15 POS 5mm Solder RA Thru-Hole TERM BLOCK HDR 15POS R/A 5MM Header for PCB plug connector MSTB 2,5/15-G MSTB25/15-G Phoenix Contact COMBICON MSTB 系列 15路 5mm节距 PCB 接线端子块 , 焊接端接, 12A |
| Category |
Business
| Product | Headers | Lead Time | 17 Days |
| Tradename | COMBICON Control | Subcategory | Connector Headers and PCB Receptacles |
| Product Category | Pluggable Terminal Blocks | Standard Package | 50 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 250 V | Current Rating (Max) | 12 A |
| Voltage - Input (Min) | 320V | ||
Mechanical
| Color | Green | Depth | 12 |
| Pitch | 0.197" (5.00mm) | Height | 8.6 |
| Weight | 2.646 lbs | Packaging | Bulk |
| Termination | Solder | Housing Color | Green |
| Mounting Type | Right Angle | Contact Finish | Tin |
| Number of Rows | 1 | Contact Material | 锡 |
| Housing Material | Polybutylene Terephthalate | Length - Overall | 75 |
| Termination Rows | 焊接 | Termination Style | Through Hole |
| Header Orientation | 90°, Right Angle | Number of Contacts | 15 |
| Number of Positions | 15 | Terminal Block Type | Header, Male Pins, Shrouded (2 Side) |
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | MSTB | Industry Aliases | MSTB 2, 5/15-G |
| Number of Levels | 1 | Positions Per Level | 15 |
