NUD4001DR2G
| Manufacturer | |
| Description | LED DRVR 3Segment 8-Pin SOIC N T/R LED Lighting Drivers MI 60V LED DRVR TR IC LED DRIVER LINEAR 8-SOIC NUD4001DR2G, LED Driver 3-Segments, 8-Pin SOIC N IC, LED DRIVER, HIGH CURRENT LEDDRIVER,60V,8PINSOIC ON Semiconductor LED 驱动器集成电路 SOIC |
| Category |
Business
| Other Names | NUD4001DR2GOSCT | Product Category | LED Lighting Drivers |
| Standard Package | Tape & Reel, Cut Tape | Factory Pack Quantity | 2500 |
| Standard Package Name | SOIC | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
Electrical
| Dimming | :- | Display Type | :LED |
| Power - Rated | 1130 mW | Voltage Rating | 30 V |
| Current - Output | :345mA | Driver Circuitry | LED |
| Voltage - Supply | 30 V | Number of Outputs | 1 |
| Voltage - Input (Min) | 28V | Voltage - Output (Max) | :28V |
| Voltage - Supply (Min) | 30 | Power Dissipation (Max) | 1130 mW |
| Constant Current Load - Max | Yes | Voltage - Continuous Operating (Max) (MCOV) | :30V |
Mechanical
| Width | 4mm | Height | 1.5mm |
| Length | 5mm | Weight | 0.0001 |
| Packaging | Reel | Case Color | :SOIC |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :8 | Package / Case | 8SOIC N |
| Package Cooled | SOIC N | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 5(Max) | Package Quantity | SOIC N |
| Size / Dimension | 5 x 4 x 1.5mm | Number of Positions | 8 |
| Shell Size - Insert | 1.5(Max) | Supplier Device Package | 8-SOIC N |
Product Info
| Type | Automotive, General Purpose | Topology | PWM |
| Control Interface | :Parallel | Number of Segments | 3 |
| Internal Connection | Yes | Application Specifics | :Battery Charging, Low Voltage Lighting |
| Printed Circuit Board | 8 | ||
Environmental
| Operating Temperature | + 125 C | Thermal Resistance @ Natural | 110°C/W |
