74HC4094N
| Manufacturer | |
| Description | 74HC4094N, 8-Bit Shift Register HC, Serial to Serial/Parallel, Uni-Directional 2 to 6V 16-Pin PDIP Shift Register/Latch Single 8-Bit Serial to Serial/Parallel 16-Pin PDIP Bulk IC, 74HC CMOS, 74HC4094, DIP16, 5V 8-STAGESHIFT&STOREBUSREG Logic IC DIL-16, 74HC4094N, NXP |
| Category |
Compliance
| RoHS | RoHS Compliant Part | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423990 | Part Status | :74HC4094 |
| Rad Hardened | No | ||
Electrical
| GPIO | :Serial to Parallel | Frequency | :95MHz |
| Logic Type | HC | Output Type | 3-State |
| Number of Bits | 8 | Operating Mode | Serial to Serial/Parallel |
| Voltage Rating | 2 V | Voltage - Supply | 5 V |
| Number of Elements | :1 | Voltage - Supply (Min) | 6 V |
| Delay Time - Propagation | 295 ns | ||
Mechanical
| Width | 6.48mm | Height | 3.2mm |
| Length | 19.5mm | Weight | 0.0012 |
| Packaging | Bulk | Termination | :Through Hole |
| Mounting Type | Through Hole | Number of Pins | :16 |
| Package / Case | :DIP | Package Cooled | PDIP |
| Material Finish | :- | Size / Dimension | 19.5 x 6.48 x 3.2mm |
| Number of Positions | 16 | Switch Actuation Level | Positive Edge |
Product Info
| Type | Not Required | Series | :HC |
| Features | Bus,Tri-State | Function | Shift Register |
| Base Unit | :74 | Technology | CMOS |
| Port Direction | Uni-Directional | Number of Stages | 8 |
| Utilized IC / Part | :74HC4094 | ||
Environmental
| Operating Temperature | +125 °C | Usable Temperature Range | -40to+125°C |
