979-025-030R121
| Manufacturer | |
| Description | D-Sub Backshells 25P TOP ENT DIECAST NICKEL PLATED BACKSHELL DB25 DIE CAST ZINC HOOD, DSUB, 45DEG, 4-40 SCREW, 25WAY |
| Category |
Business
| Tradename | ARMOR | Product Category | D-Sub Backshells |
| Standard Package | 50 | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | Material Flammability Rating | UL 94 HB |
Mechanical
| Color | Silver | Weight | 0.0624 |
| Plating | Nickel | Material | Metal, Zinc Alloy |
| Packaging | Bulk | Shielding | Shielded |
| Cable Exit | 180° | Cable Type | Round |
| Shell Size | :DB | Shell Plating | Nickel over Copper |
| Cable End Type | Straight | Shell Material | Zinc Die Cast |
| Material - Body | :Zinc | Material Finish | :- |
| Number of Positions | 25 | Number of Cable Pairs | 1 |
Product Info
| Type | Strain Relief Backshell | Series | 979 |
| Features | Mating Screws 4-40, Sealed | Hardware | Assembly Hardware, Grommets |
| Accessory Type | Two Piece Backshell | ||
