180-015-172L000
| Manufacturer | |
| Description | D-Sub High Density Connectors 15P Male CONN DB15 MALE HD CRIMP TIN |
| Category |
Business
| Product Category | D-Sub High Density Connectors | Standard Package | 50 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Current Rating (Max) | 5 A | ||
Mechanical
| Height | 12.6 mm | Packaging | Tray |
| Insulation | Insulated | Contact Type | Signal |
| Mounting Type | Straight | Shell Plating | Tin |
| Connector Type | Plug for Male Contacts | Flange Feature | Housing/Shell (Unthreaded) |
| Mounting Style | Panel | Number of Rows | 3 |
| Shell Material | Steel | Connector Style | D-Sub, High Density |
| Termination Style | Solder | Number of Contacts | 15 |
| Number of Positions | 15 | Shell Material, Finish | Steel, Tin Plated |
| Shell Size, Connector Layout | 1 (DE, E) High Density | ||
Product Info
| Note | Contacts Not Provided | Gender | Male |
| Features | Shielded | ||
Environmental
| Operating Temperature | -50°C ~ 100°C | ||
