0836129020
| Manufacturer | |
| Description | Conn Commercial Micro-D PIN 15 POS 1.27mm Solder RA Thru-Hole 15 Terminal 1 Port Tube CONN PLUG MICRO-D 15POS R/A PCB PLUG, MICRO D, PCB, R/A, 15WAY |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85369010 |
| Approval Agency | :CSA, UL | Material Flammability Rating | :UL94V-0 |
Electrical
| Range deg/s | :MOLEX - Commercial Micro-D Series | Voltage Rating | 350V |
| Voltage - Working | :350V | Contact Resistance | :8mohm |
| Voltage - Breakdown | :650V | Current Rating (Max) | 1A |
| Insulation Resistance | :5000Mohm | Voltage - Input (Min) | 350VAC |
Mechanical
| Pitch | 1.27 mm | Height | 7.82 |
| Weight | 0.017 | Material | :Stainless Steel |
| Packaging | Tube | Shell Size | :DA |
| Termination | Solder | Contact Type | Signal |
| Mounting Type | Through Hole | Connector Type | Plug, Male Pins |
| Contact Finish | Gold | Flange Feature | Mating Side; Female Screwlock (2-56) |
| Number of Rows | 2 | Package / Case | :Micro D plug R/A |
| Connector Style | D-Type, Micro-D | Material - Body | :- |
| Housing Material | Liquid Crystal Polymer (LCP) | Insulation Color | :Black |
| Length - Overall | 23.75 | 1st Contact Gender | PIN |
| Number of Contacts | 15 | Contact Termination | :Solder |
| Number of Positions | 15 | Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | 15µin (0.38µm) | Material - Housing & Prism | :Nickel Plated |
| Shell Size, Connector Layout | 0.050 Pitch x 0.050 Row to Row | ||
Product Info
| Type | Commercial Micro-D | Gender | PIN |
| Series | :83612 | Features | Board Lock, Shielded |
| Number of Ports | 1 | ||
Environmental
| Mating Cycles | :500 | Operating Temperature | -55°C ~ 125°C |
