0757571201
| Manufacturer | |
| Description | Conn Unshrouded Header HDR 20 POS 3.5mm Solder ST Thru-Hole Tube CONN HEADER 2X10 STR BRKWAY GOLD |
对参数有疑问？问 AI 助手
Business
| Standard Package | 270 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 16/Contact | Voltage - Input (Min) | 500VDC |
Mechanical
| Color | Black | Depth | 9.6 |
| Pitch | 0.138" (3.50mm) | Height | 15.7 |
| Packaging | Tube | Row Spacing | 0.236" (6.00mm) |
| Termination | Solder | Contact Type | Male Pin |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Header, Unshrouded, Breakaway | Contact Finish | Gold |
| Number of Rows | 2 | Contact Material | Brass |
| Housing Material | Thermoplastic | Length - Overall | 51.1 |
| Number of Contacts | 20 | Number of Positions | 20 |
| Contact Length - Mating | 0.441" (11.20mm) | Contact Finish Thickness | 2µin (0.05µm) |
Product Info
| Type | Unshrouded Header | Gender | HDR |
| Number of Positions Loaded | All | ||
