0022162050

Manufacturer	Molex, LLC
Description	Conn Socket Strip RCP 5 POS 2.54mm Solder RA Thru-Hole Tray CONN RECEPT 5POS .100 R/A PCB
Category	Connector SolutionsRectangular ConnectorsPower Hybrid Rectangular Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Trays

Compliance

RoHS

Lead free / RoHS Compliant

EU RoHS

Compliant

Electrical

Contact Resistance	20	Current Rating (Max)	2.5/Contact
Voltage - Input (Min)	250V

Mechanical

Color	White	Depth	7.9
Pitch	2.54 mm	Height	4.7
Packaging	Tray	Termination	Solder
Contact Type	Female Socket	Housing Color	White
Mounting Type	Through Hole	Connector Type	Receptacle
Contact Finish	Gold Over Nickel	Number of Rows	1
Contact Material	Brass	Housing Material	Nylon
Length - Overall	12.6	Number of Contacts	5
Number of Positions	5	Contact Finish Thickness	15µin (0.38µm)

Product Info

Type	Socket Strip	Gender	RCP
Number of Positions Loaded	All

Documents & Media

PDF Document

Resin Color 01/Jan/2002

PDF Document

0022162050_PCB_RECEPTACLES.pdf
