0009508031

Manufacturer	Molex, LLC
Description	Conn Housing RCP 3 POS 3.96mm Crimp ST Bag CONN HOUSING 3POS .156 W/RAMP
Category	Connector SolutionsHeavy Duty ConnectorsHeavy Duty Connectors

对参数有疑问？问 AI 助手

Business

Lead Time	36 Days	Subcategory	Connector Discrete Wire Housing
Standard Package	Bulk

Compliance

RoHS

Lead free / RoHS Compliant

EU RoHS

Compliant

Electrical

Current Rating (Max)	7/Contact A	Voltage - Input (Min)	250VAC
Voltage - Supply (Min)	250VAC

Mechanical

Color	Natural	Depth	15.88 mm
Pitch	3.96 mm	Height	8.07 mm
Packaging	Bag	Contact Type	Non Gendered
Housing Color	Natural	Mounting Type	Straight
Connector Type	Receptacle	Fastening Type	Locking Ramp
Number of Rows	1	Housing Material	Polyester
Length - Overall	12.75 mm	Number of Contacts	3
Contact Termination	Crimp	Number of Positions	3

Product Info

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Industry Aliases	09-50-8031, 09508031, 9508031

Environmental

Operating Temperature

0C to 75C

Documents & Media

PDF Document

0009508031_CRIMP_HOUSINGS.pdf

PDF Document

09-50-8031
