51021-0500
| Manufacturer | |
| Description | CONN HOUSING 5POS 1.25MM 5 way receptacle housing,1.25mm pitch Headers & Wire Housings RECEPTACLE 5 POS Conn Housing F 5 POS 1.25mm Crimp ST Cable Mount Bag CRIMP HOUSING, 1.25MM, 5WAY 1.25mm Wire-to-Board Receptacle Housing; 5 Circuit Crimp housing 1.25 mm Poles 5 PicoBlade, 51021-0500, Molex Molex PICOBLADE 系列 1 行 1.25mm 节距 5 路 直 母 电缆安装 压接连接器外壳 |
| Category |
Business
| Tradename | PicoBlade | Part # Aliases | 0510210500 |
| Product Category | Headers & Wire Housings | Factory Pack Quantity | 2000 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
Electrical
| Range deg/s | :MOLEX - PicoBlade 51021 Series | Voltage Rating | :125V |
| Voltage - Working | :125V | Contact Resistance | :20mohm |
| Dielectric Strength | :250V | Current Rating (Max) | :1A |
| Insulation Resistance | :100Mohm | ||
Mechanical
| Depth | 3.95mm | Pitch | 1.25mm |
| Width | 3.2mm | Length | 8mm |
| Weight | 0.002 | Termination | :Crimp |
| Mounting Type | Straight | Contact Finish | :Tin |
| Mounting Style | Wire | Number of Rows | 1 |
| Package / Case | :GF Nylon UL94V-0 | Contact Material | :Phosphor Bronze |
| Housing Material | PBT | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 5 |
| Contact Termination | :Crimp | 1st Connector Mounting Type | :PCB |
Product Info
| Gender | Female | Series | 51021 |
| CAD Drawing | 3D CAD Model | Product Type | Receptacles / Sockets - Housings |
| For Use With/Related Products | PicoBlade Wire-to-Board Connector, PicoBlade Wire-to-Wire Connector | ||
Environmental
| Operating Temperature | :85°C | ||
Documents & Media
Similar Parts
06-66-0013
Molex
Cable Assemblies 50058 12 CUSTOM Socket to socket crimped lead,300mm L Specialized Cables 50058 12 CUSTOM Discrete Wire, 28AWG, 0.30m RED -wire LEAD, SKT/SKT, 300MM, 28AWG, PK10 Pre-crimped lead 2 x female 300 mm red, 06-66-0013, Molex Molex 测试引线 300mm长
06-66-0012
Molex
Cable Assemblies 1.25 MM 28 AWG DISCRETE CABLE Socket to socket crimped lead,150mm L Specialized Cables 1.25 MM 28 AWG DISCRETE CABLE Cable Assembly Discrete Wire 0.152m 28AWG Crimp Terminal to Crimp Terminal F-F Crimp-Crimp Bag LEAD, SKT/SKT, 150MM, 28AWG, PK10 Pre-crimped lead 2 x female 150 mm red, 06-66-0012, Molex Molex 测试引线 150mm长
06-66-0015
molex
Cable Assembly 0.304m 28AWG Crimp Terminal F Crimp Cable Assemblies DISCRETE WIRE 28AWG 0.30M RED Socket to free end crimped lead,300mm L Specialized Cables DISCRETE WIRE 28AWG 0.30M RED LEAD, SKT/FREE END, 300MM, 28AWG, PK10 Pre-crimped lead 1 x female-1 x free end 300 mm red, 06-66-0015, Molex Molex 测试引线 300mm长
532610571
molex
Conn Shrouded Header HDR 5 POS 1.25mm Solder RA SMD Embossed T/R 05 P HEADER SHROUDED 90° SMT HEADER, SMT, RIGHT ANGLE, 1.25MM, 5WAY
53398-0571
molex
Conn Shrouded Header HDR 5 POS 1.25mm Solder ST SMD Embossed T/R Molex 53398 Series 1.25mm Pitch 5 Way 1 Row Straight PCB Header, Solder Termination, 1A Headers & Wire Housings VERTICAL HDR SMT 5P HEADER, VERTICAL, SMT, 5WAY WIRE-BOARD CONNECTOR HEADER 5POS, 1.25MM Conn; Rect; Header; 1.25 mm Pitch; PCB; 5 Cir; Ver; PicoBlade; LF Pin header SMD 1.25 mm Poles 5 PicoBlade, 53398-0571, Molex Molex PICOBLADE 系列 1.25mm节距 5路 (1排) 直 PCB 针座, 焊接端接, 1A , 表面安装
50079-8000
molex
Contact SKT Crimp ST Cable Mount Reel Headers & Wire Housings TERMINAL 26-28 REEL Crimp terminal,1.25mm, 26-28AWG Headers & Wire Housings PCBLD TERM 26-28G F Reel of 25000 CONTACT, SOCKET, 26AWG, CRIMP CONTACT, CRIMP, RECEPTACLE, 26AWG, REEL 049 pitch picoblade crimp terminal 26-28 awg 25k ree; Crimp contact reel Female 28...26 AWG, 50079-8000, Molex Molex PICOBLADE 系列 母 压接接线端子, 压接, 镀锡触点
51021-0500
Molex Connector Corporation
CONN HOUSING 5POS 1.25MM 5 way receptacle housing,1.25mm pitch Headers & Wire Housings RECEPTACLE 5 POS Conn Housing F 5 POS 1.25mm Crimp ST Cable Mount Bag CRIMP HOUSING, 1.25MM, 5WAY 1.25mm Wire-to-Board Receptacle Housing; 5 Circuit Crimp housing 1.25 mm Poles 5 PicoBlade, 51021-0500, Molex Molex PICOBLADE 系列 1 行 1.25mm 节距 5 路 直 母 电缆安装 压接连接器外壳
51022-0500
