15-47-4023
| Manufacturer | |
| Description | CONN FFC FEMALE 2POS .100 GOLD FFC & FPC Connectors SL FFC/FPC Opt G Fem 15 SAu 2Ckt Conn IDC Connector F 2 POS 2.54mm IDT ST Cable Mount Tube |
| Category |
Business
| Tradename | C-Grid | Part # Aliases | 0015474023 A704300316 |
| Product Category | FFC & FPC Connectors | Standard Package | 1 |
| Factory Pack Quantity | 3120 | ||
Compliance
| RoHS | RoHS Compliant | Material Flammability Rating | UL94 V-0 |
Electrical
| Voltage Rating | 250V | Current Rating (Max) | 1 A, 2 A |
Mechanical
| Color | Black | Pitch | 0.100" (2.54mm) |
| Packaging | Tube | Termination | IDC |
| Mounting Type | Vertical | Connector Type | Receptacle |
| Contact Finish | Gold | Mounting Style | Cable |
| Contact Material | Phosphor Bronze | Housing Material | Polyester, Glass Filled |
| Termination Style | IDC | FFC, FCB Thickness | 0.30mm |
| Number of Contacts | 2 | Number of Positions | 2 |
| Contact Finish Thickness | 15µin (0.38µm) | ||
Product Info
| Gender | Female | Series | 70430 |
| Features | Latch Lock | Product Type | Free Hanging |
Environmental
| Operating Temperature | -40°C ~ 105°C | ||
Documents & Media
Similar Parts
0705430001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT GOLD
0701070001
molex
Conn Housing F 2 POS 2.54mm Crimp ST Bag Conn Housing F 2 POS 2.54mm Crimp ST Cable Mount Bag CONN HOUSING MALE 2POS .100 Connector: wire-wire; SL; plug; male; w/o terminals; PIN:2; 2.54mm
0705550036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A 15AU
0705530001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A GOLD
0705530106
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A 30AU
0622020800
molex
FFC/SL TOOLING 2-20 CKT W/ TM42 PRESS TM-42 PRESS AND TERMINATION KIT FOR 110V APPLICATIONS FFC/SL TOOL 2-20 CKT W/ TM42
0623003000
molex
RIBBON CABLE HAWK W/O BREAK-OFF STATION HAWK Ribbon Cable Terminator For SL Without Break-Off RIBBON CABLE HAWK
0705450036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT 15AU
0623005200
molex
FFC HAWK W/ BREAK-OFF STATION HAWK FLAT FLEX CABLE TERMINATOR FOR SL WITH BREAK-OFF
0705430106
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT 30AU
0705550001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A TIN
0705430036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HDR VERT 2POS .100 TIN
0705530036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HDR RT ANG 2POS .100 TIN
68301-1054
Molex
Headers & Wire Housings 2.54MM BREAKAWAY Vertical 2 CKT CONN HEADER 2POS .100" VERT TIN
0015913024
