PIC18F2520-I/SO
| Manufacturer | |
| Description | MCU 8-Bit PIC18 PIC RISC 32KB Flash 5V 28-Pin SOIC W Tube MCU 8-bit PIC18 PIC RISC 32KB Flash 5V 28-Pin SOIC W Tube 8 bit MCU SOIC28 IC MCU 8BIT 32KB FLASH 28SOIC PIC18F2520-I/SO, 8 bit Microcontroller PIC 40MHz 32kb Flash, 1536B RAM, I2C SPI 28-Pin SOIC IC, 8BIT FLASH MCU, 18F2520, SOIC28 IC, 8BIT FLASH MCU, TUBE27, 18F2520 28-Pin,32KBFlash,1536RAM,25I/O PIC microcontroller; EEPROM:256B; SRAM:1536B; 40MHz; SO28; 2÷5.5V Microcontroller 8 Bit SO-28, PIC18F2520-I/SO, Microchip Microchip PIC18F 系列 8 bit PIC MCU, 40MHz, 32 kB、256 B ROM 闪存, 1536 B RAM, 28针 SOIC封装 8-bit Microcontrollers - MCU 32KB 1536 RAM 25I/0 PIC18F 32K SOIC28 85°C |
| Category |
Business
| MOQ | 162 | Unit Pack | 27 |
| Other Names | PIC18F2520ISO | Standard Package | Rail / Tube |
| Standard Package Name | SOIC W | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Part Status | :18F2520 | Rad Hardened | No |
| Leadfree Defin | RoHS-conform | Approval Agency | No |
Electrical
| Input | 25 | Speed | 40 MHz |
| Timer | 1 x 8 bit, 3 x 16 bit | Memory | 32KBytes |
| RAM Size | 1.5 KB | Core Size | 8-Bit |
| Core Type | PIC | Frequency | 40 MHz |
| Interface | I2C/SPI/USART | Clock Rate | 40 |
| Comparator | 2 | EEPROM Size | 256Byte |
| Memory Size | 32KByte | Memory Type | FLASH |
| Display Type | no | Number of I/O | 25 |
| Voltage Range | 2-5.5V | Number of Bits | 10 |
| Voltage Rating | 4.2 → 5.5 V | Watchdog Timer | 1 |
| Clock Frequency | :40MHz | Data Converters | A/D 10x10b |
| Frequency - Max | 40MHz | Number of DAC's | 2 |
| Oscillator Type | Internal | Interrupt Output | :19 |
| Voltage - Supply | 5 V | Digital I/O Lines | 24pins |
| Resolution (Bits) | 10Bit | Serial Interfaces | 1 |
| Number of Channels | 1 | Analog Input:Output | 2 |
| Non-Volatile Memory | 256Bytes | Program Memory Size | 32 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 10 |
| Voltage - Input (Min) | 5.5V | Number of 8-bit Timers | 1 |
| Voltage - Supply (Min) | 4.2 V | Frequency (Center/Band) | 16 bit, 8 bit |
| Power Dissipation (Max) | 1000 mW | Number of Bits per Element | :16 |
| Voltage - Supply (Vcc/Vdd) | 4.2 V ~ 5.5 V | ||
Mechanical
| Width | 7.5mm | Height | 2.35mm |
| Length | 17.9mm | Weight | 0.0001 |
| Packaging | TUBE | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Number of Pins | :28 |
| Package / Case | 28SOIC W | Package Cooled | SOIC |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 17.9 |
| Package Quantity | SOIC W | Size / Dimension | 17.9 x 7.5 x 2.35mm |
| Number of Positions | 28 | Shell Size - Insert | 2.05(Min) |
| Supplier Device Package | 28-SOIC | Number of Cores/Bus Width | 8 Bit |
| Pulse Width Distortion (Max) | 2(CCP) | ||
Product Info
| SPI | 1 | Spg | 162 |
| USB | yes | Type | PIC microcontroller |
| Protocol | 1 | Matchcode | PIC18F2520-I/SO |
| CAN Number | 0 | Flash Size | :32KB |
| SPI Number | 1 | On-Chip RAM | 10-chx10-bit |
| Peripherals | Brown-out Detect/Reset, HLVD, POR, PWM, WDT | Architecture | RISC |
| Connectivity | I²C, SPI, UART/USART | Programmable | Yes |
| Core Processor | PIC | Built in Switch | 32kHz, 8MHz |
| Number of Units | 1 | Number of Timers | 4 |
| Controller Series | :PIC18 | Standard Leadtime | 14 weeks |
| RF Family/Standard | PIC18 | Utilized IC / Part | :PIC18F2520-I/SO |
| DigiKey Programmable | Yes | Printed Circuit Board | 28 |
| Microcontroller Features | :SPI, I²C, 2 x CCP, EUSART, 2 x Comparators, 1 x 8-bit timer, 3 x 16-bit timer | Number of A/D Converters | :10 |
Environmental
| Temperature Range | :Industrial | Temperature - Test | 85°C |
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
