PIC18F1320-I/P
| Manufacturer | |
| Description | MCU 8-bit PIC18 PIC RISC 8KB Flash 5V 18-Pin PDIP Tube 8 bit MCU PDIP18 IC MCU 8BIT 8KB FLASH 18DIP PIC18F1320-I/P, 8 bit Microcontroller PIC 40MHz 8kb Flash, 256B RAM, 18-Pin PDIP 8-bit Microcontrollers - MCU 8KB 256 RAM 16 I/O IC, 8BIT FLASH MCU, 18F1320, DIP18 IC, 8BIT FLASH MCU, TUBE25, 18F1320 Microcontroller;8KBFlash;256RAM;256EEPROM;16I/O;PDIP-18 PIC microcontroller; EEPROM:256B; SRAM:256B; 40MHz; DIP18; 2÷5.5V Microcontroller 8 Bit DIL-18, PIC18F1320-I/P, Microchip Microchip PIC18F 系列 8 bit PIC MCU, 40MHz, 8 kB、256 B ROM 闪存, 256 B RAM, 18针 PDIP封装 PIC18F 8K PDIP18 85°C |
| Category |
Business
| MOQ | 25 | Unit Pack | 25 |
| Other Names | PIC18F1320IP | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 25 |
| Standard Package Name | PDIP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Automotive | NO | Part Status | :18F1320 |
| Rad Hardened | No | Leadfree Defin | RoHS-conform |
| Approval Agency | No | ||
Electrical
| Input | 16 | Speed | 40 MHz |
| Timer | 1 x 8 bit, 1 x 8/16 bit, 2 x 16 bit | Memory | 8KBytes |
| Ethernet | 0 | RAM Size | 256 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Frequency | 40 MHz | Interface | USART |
| Clock Rate | 40 MHz | Comparator | 0 |
| EEPROM Size | 256Byte | Memory Size | 8KByte |
| Memory Type | FLASH | Display Type | 0 |
| Number of I/O | 16 | Voltage Range | 2-5.5V |
| Number of Bits | 10 | Voltage Rating | 4.2 → 5.5 V |
| Watchdog Timer | 1 | Clock Frequency | :40MHz |
| Data Converters | A/D 7x10b | FPGA Core Cells | :10 |
| Frequency - Max | 40MHz | Number of DAC's | 1 |
| Oscillator Type | Internal | Voltage - Supply | 5 V |
| Digital I/O Lines | 15pins | Resolution (Bits) | 16bit |
| Serial Interfaces | 1 | Number of Channels | 0 |
| Analog Input:Output | 7-Channel,10-Bit | Non-Volatile Memory | 256Bytes |
| Program Memory Size | 8 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 7 | Voltage - Input (Min) | 5.5V |
| Number of 8-bit Timers | 1 | Voltage - Supply (Min) | 4.2 V |
| Frequency (Center/Band) | 16 bit, 8 bit | Power Dissipation (Max) | 1000 mW |
| Number of Bits per Element | 10 bit | Voltage - Supply (Vcc/Vdd) | 4.2 V ~ 5.5 V |
Mechanical
| Width | 0.28in | Height | 0.195in |
| Length | 0.92in | Weight | 0.000001 |
| Packaging | TUBE | Lead Style | Through Hole |
| Termination | :Through Hole | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Number of Pins | :18 |
| Package / Case | 18PDIP | Package Cooled | PDIP |
| Material Finish | :- | Package Quantity | PDIP |
| Size / Dimension | 0.92 x 0.28 x 0.195in | Number of Positions | 18 |
| Supplier Device Package | 18-PDIP | Number of Cores/Bus Width | 8 Bit |
| Pulse Width Distortion (Max) | 1(ECCP) | ||
Product Info
| Spg | 225 | USB | No |
| Type | PIC microcontroller | Series | PIC18 |
| Matchcode | PIC18F1320-I/P | CAN Number | 0 |
| Flash Size | :8KB | SPI Number | 0 |
| On-Chip RAM | 7-chx10-bit | Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT |
| Architecture | RISC | Connectivity | UART/USART |
| Programmable | Yes | Core Processor | PIC |
| Built in Switch | 32kHz, 8MHz | Number of Units | 1 |
| Number of Timers | 4 | Controller Series | :PIC18 |
| Standard Leadtime | 14 weeks | RF Family/Standard | PIC18 |
| Utilized IC / Part | :PIC18F1320-I/P | DigiKey Programmable | Yes |
| Microcontroller Features | :ADC, BOR, PWM, TIMERS, USART, WDT | Number of A/D Converters | :7 |
Environmental
| Temperature Range | :Industrial | Temperature - Test | -40°C |
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
