MCP4241-503E/P
| Manufacturer | |
| Description | Digital Potentiometer 128POS 50KOhm Dual 14-Pin PDIP Tube Digital Potentiometer ICs Dual 7B NV SPI POT IC DGTL POT DL 50K 2CH 14-DIP Potentiometer 50k, 128-step SPI NV dual PEAK RE Potentiometer50k,128-stepSPINVdual 2通道 50kΩ 129位置 线性 数字电位计, 串行 - SPI接口, 8针 PDIP封装 |
| Category |
Business
| Product Category | Digital Potentiometer ICs | Standard Package | Rail / Tube |
| Factory Pack Quantity | 30 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85423990 |
Electrical
| Interface | Serial (4-Wire, SPI) | Resistance | 50 kOhm |
| Memory Type | Non-Volatile | Current - Output | 550 uA |
| Voltage - Supply | 2.5 V, 3.3 V, 5 V | Power Supply Type | Single |
| Resistance (Ohms) | 50k | ||
Mechanical
| Taper | Linear | Width | 0.28in |
| Height | 0.195in | Length | 0.4in |
| Weight | 0 | Packaging | Tube |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Package / Case | 14PDIP | Package Cooled | PDIP |
| Size / Dimension | 0.4 x 0.28 x 0.195in | Number of Positions | 128 |
| Supplier Device Package | 14-PDIP | ||
Product Info
| Wiper Memory | Non Volatile | Control Interface | Serial (4-Wire, SPI) |
| Number of Circuits | 2 | Number of Taps/Steps | 128 |
| Number of A/D Converters | Dual | ||
Environmental
| Operating Temperature | -40 to 125 °C | Temperature Coefficient | 150 ppm/°C Typical |
