MCP23S09-E/SO
| Manufacturer | |
| Description | . MCP23S09-E/SO - I/O Expander 8 SPI 10 MHz 18-SOIC from Microchip Technology. from now! |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 336 | Product | I/O Expanders |
| Unit Pack | 42 | Other Names | MCP23S09ESO |
| Product Category | Interface - I/O Expanders | Standard Package | Bulk |
| Factory Pack Quantity | 42 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Automotive | NO |
Electrical
| Channels | 8 | Data Rate | 10kbps |
| Interface | SPI | Clock Rate | 3.4 MHz |
| Logic Type | MCP23S09 | Output Type | Open Drain |
| Number of I/O | 8 | Power - Rated | 700 mW |
| Voltage Rating | 1.8 V to 4.5 V | Clock Frequency | 10MHz |
| Frequency - Max | 3.4 MHz | Current - Output | 25 mA |
| Interrupt Output | Yes | Voltage - Supply | 1.8 V ~ 5.5 V |
| Frequency - Output 1 | 10MHz | Voltage - Input (Min) | 1.8V |
| Power - Average Forward | 700 mW | Delay Time - Propagation | 50 ns |
| Current - Output Source/Sink | 25mA | ||
Mechanical
| Weight | 3.9 g | Footprint | 119mm² |
| Packaging | TUBE | Mounting Type | SMD |
| Mounting Style | SMD/SMT | Number of Pins | 18 |
| Package / Case | 18SOIC W | Package Cooled | SOIC |
| Connector Usage | SPI | Top Termination | 125°C |
| Package Quantity | 42 | Primary Material | Microcontroller |
| Number of Contacts | 18 | Minimum Working Height | -40°C |
| Supplier Device Package | 18-SOIC | ||
Product Info
| Spg | 42 | Type | IO-Expand. |
| Matchcode | MCP23S09-E/SO | Manufacturer | Microchip Technology |
| Product Type | I/O Expanders | Number of Units | 1 |
| Standard Leadtime | 14 weeks | Utilized IC / Part | 8bit I/O port |
| Output Configuration | Surface Mount | For Use With/Related Products | 8-BitInput/Output,SPIinterface(SOIC-18) |
Environmental
| Operating Temperature | -40 to 125 °C | ||
